Table PD-7 — Gross Cooling Capacities SAVE-075
English
ENT Water Temp (°F)
75
85
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
79.4
64.2
18.1
89.4
49.9
19.8
100.1
35.3
22.0
77.2
63.1
18.1
86.8
48.8
19.8
97.1
34.2
22.0
2700
80
79.8
75.6
18.1
89.3
61.6
19.8
100.0
47.0
22.0
77.7
74.3
18.1
86.7
60.6
19.8
97.0
46.0
22.0
85
82.5
81.7
18.5
89.1
71.5
19.8
99.9
56.8
22.0
80.6
79.8
18.5
86.6
70.4
19.8
97.0
55.8
22.0
90
86.5
85.7
19.4
89.4
81.1
19.8
99.7
66.6
22.0
84.5
83.7
19.4
86.8
79.9
19.8
96.9
65.5
21.6
75
80.5
66.3
18.1
90.4
51.1
20.3
101.2
35.7
22.5
78.1
65.2
18.1
87.9
50.0
20.3
98.3
34.5
22.0
2925
80
81.1
78.1
18.5
90.3
63.6
20.3
101.1
48.2
22.5
79.0
76.8
18.5
87.6
63.0
20.3
98.2
47.0
22.0
85
84.4
83.6
18.9
90.3
74.0
20.3
101.0
58.5
22.0
82.5
81.7
18.9
87.6
72.9
20.3
98.1
57.4
22.0
90
88.5
87.7
19.8
90.6
84.0
20.3
100.9
68.8
22.0
86.5
85.7
19.8
88.1
82.7
20.3
97.9
67.7
22.0
75
81.3
68.4
18.5
91.5
52.3
20.3
102.3
36.0
22.5
79.0
67.2
18.5
88.7
51.2
20.3
99.2
34.9
22.5
3150
80
124.4
80.3
18.5
91.4
65.5
20.3
102.2
49.1
22.5
80.2
78.9
18.5
88.6
64.4
20.3
99.1
48.1
22.5
85
86.1
85.3
19.4
91.3
76.4
20.3
102.1
60.1
22.5
84.1
83.3
19.4
88.6
75.4
20.3
99.0
59.0
22.5
90
90.3
89.5
20.3
91.8
86.7
20.3
102.0
71.0
22.5
88.3
87.5
20.3
89.3
85.4
20.3
98.9
69.8
22.0
75
82.2
70.2
18.5
92.3
53.4
20.7
103.1
36.3
22.5
79.7
69.2
18.5
89.6
52.3
20.3
100.1
35.2
22.5
3375
80
83.5
82.3
18.9
92.2
67.3
20.3
103.0
50.2
22.5
81.4
80.6
18.9
89.5
66.2
20.3
100.0
49.0
22.5
85
87.7
86.8
19.8
92.1
78.9
20.7
103.0
61.6
22.5
85.6
84.8
19.8
89.4
77.7
20.3
99.9
60.5
22.5
90
92.1
91.2
20.3
93.0
89.3
20.7
102.9
73.1
22.5
89.9
89.0
20.3
90.4
87.8
20.7
99.7
71.9
22.5
Table PD-7 — Gross Cooling Capacities SAVE-075 (Cont.)
ENT Water Temp (°F)
95
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
74.7
62.0
18.1
84.1
47.7
19.8
94.0
33.2
21.6
2700
80
75.4
73.0
18.1
84.0
59.4
19.8
94.0
44.9
21.6
85
78.5
77.8
18.5
84.0
69.2
19.8
93.9
54.6
21.6
90
82.5
81.7
19.4
84.3
78.6
19.8
93.8
64.4
21.6
75
75.6
63.0
18.1
85.0
48.9
19.8
95.1
33.5
22.0
2925
80
76.7
75.2
18.5
84.9
61.4
19.8
95.0
46.0
22.0
85
80.3
79.6
18.9
84.9
71.7
19.8
95.0
56.3
22.0
90
84.4
83.6
19.8
85.5
81.4
20.3
94.9
66.6
22.0
75
76.4
66.0
18.1
85.9
50.1
20.3
96.0
33.8
22.0
3150
80
78.0
77.1
18.5
85.8
63.2
20.3
95.9
46.9
22.0
85
81.9
81.2
19.4
85.8
74.1
20.3
95.8
57.9
22.0
90
86.1
85.3
20.3
86.7
83.9
20.3
95.7
68.8
22.0
75
77.2
68.0
18.5
86.6
51.1
20.3
96.8
34.1
22.5
3375
80
79.3
78.5
18.9
86.5
65.0
20.3
96.7
47.9
22.5
85
83.4
82.6
19.8
86.5
76.4
20.3
96.7
59.4
22.0
90
87.6
86.7
20.3
87.9
86.1
20.3
96.6
70.8
22.0
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Capacity Correction Factor Table
Delta T
Water
Total Cap.
Sens. Cap.
(°F)
GPM
MBh
MBh
4.5
2.21
1.01
1.01
7.2
1.39
1.01
1.01
10.0
1.00
1.00
1.00
12.6
0.79
0.99
1.00
15.3
0.66
0.99
1.00
18.0
0.56
0.98
0.99
Performance
Data
Water Cooled
60 Hz
