Performance data air cooled 60 hz – Trane Genius PKG-PRC007-EN User Manual
Page 30
PKG-PRC007-EN
30
Table PD-13 — Gross Cooling Capacities SRVE-100
English
Ambient Temperature (°F)
85
95
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(ºF)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
75
107.1
86.8
120.1
66.3
134.0
45.5
103.8
85.1
116.3
64.6
129.7
43.8
3600
80
107.7
102.8
119.9
82.8
133.9
62.0
104.4
100.9
116.2
81.2
129.6
60.4
85
111.1
111.1
119.9
96.6
133.7
75.6
108.3
108.3
116.1
94.9
129.5
74.1
90
116.4
116.4
120.0
110.1
133.6
89.4
113.5
113.5
116.4
108.3
129.4
87.7
75
108.6
89.7
121.5
67.9
135.5
45.9
105.1
88.1
117.6
66.4
131.1
44.4
3900
80
109.3
106.4
121.4
85.6
135.4
63.4
106.1
104.3
117.5
85.5
131.0
61.9
85
113.7
113.7
121.3
100.2
135.3
78.0
110.7
110.7
117.4
98.5
130.9
76.4
90
119.0
119.0
121.6
114.1
135.2
92.5
116.1
116.1
118.0
112.3
130.8
90.9
75
109.8
92.5
122.7
69.5
136.8
46.3
106.2
90.9
118.8
68.0
132.3
44.7
4200
80
110.9
109.4
122.6
88.2
136.7
64.9
107.8
107.1
118.7
86.5
132.2
63.3
85
116.0
116.0
122.5
103.6
136.6
80.2
113.0
113.0
118.6
101.9
132.1
79.1
90
121.5
121.5
123.3
117.9
136.5
95.5
118.5
118.5
119.6
116.0
132.0
94.0
75
110.7
95.4
123.8
71.2
138.0
46.8
107.1
93.6
119.9
69.5
133.4
45.1
4500
80
112.6
112.2
123.7
90.7
137.8
66.3
109.4
109.4
119.8
89.1
133.3
64.6
85
118.0
118.0
123.7
106.9
137.7
82.4
115.0
115.0
119.7
105.2
133.2
80.8
90
123.8
123.8
124.8
121.4
137.6
98.4
120.7
120.7
121.2
119.4
133.1
96.9
Table PD-13 — Gross Cooling Capacities SRVE-100 (Cont.)
English
Ambient Temperature (°F)
105
115
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(ºF)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
75
100.4
83.5
112.4
63.0
125.2
42.2
96.9
81.9
108.2
61.3
120.2
40.4
3600
80
101.2
99.0
112.3
79.6
125.1
58.8
97.9
96.8
108.1
77.8
120.1
57.0
85
105.4
105.4
112.2
93.3
125.0
72.5
102.4
102.4
108.0
91.6
120.0
70.6
90
110.5
110.5
112.6
106.4
124.9
86.1
107.3
107.3
108.7
104.3
119.9
84.3
75
101.6
86.4
113.6
64.6
126.4
42.6
97.9
84.8
109.3
62.9
121.4
40.9
3900
80
102.9
102.0
113.5
82.3
126.3
60.2
99.6
99.5
109.2
80.6
121.3
58.4
85
107.8
107.8
113.5
96.9
126.2
74.8
104.5
104.5
109.2
95.0
121.2
72.9
90
112.9
112.9
114.2
110.3
83.0
89.3
109.5
109.5
110.3
107.9
121.1
87.4
75
102.6
89.3
114.7
66.3
127.6
43.1
98.9
87.5
110.3
64.5
122.4
41.2
4200
80
104.6
104.5
114.6
84.9
127.5
61.6
101.5
101.5
110.2
83.1
122.3
59.7
85
109.9
109.9
114.6
100.3
127.4
77.0
106.5
106.5
110.2
98.4
122.2
75.1
90
115.2
115.2
115.9
113.7
127.3
92.2
111.6
111.6
111.8
111.1
122.1
90.4
75
103.6
92.0
115.6
67.8
128.6
43.5
99.8
90.3
111.2
66.1
123.3
41.6
4500
80
106.4
106.4
115.5
87.4
128.5
62.9
103.1
103.1
111.1
85.6
123.2
61.0
85
111.8
111.8
115.6
103.4
128.4
79.1
108.3
108.3
111.2
101.6
123.1
77.3
90
117.3
117.3
117.4
116.6
128.3
95.2
113.6
113.6
113.5
113.5
123.0
93.3
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Performance
Data
Air Cooled
60 Hz
