Table PD-15 — Gross Cooling Capacities SRVE-150
Metric
Ambient Temperature (°C)
29.5
35.0
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
16.0
19.5
23.0
DB
m3/h
(ºC)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
24
47.2
39.8
52.6
30.1
58.5
20.4
45.5
39.0
50.7
29.4
56.3
19.6
9180
27
47.9
46.7
52.6
38.0
58.4
28.2
46.4
45.5
50.7
37.2
56.3
27.4
29
50.2
49.2
52.6
44.5
58.4
34.6
48.7
47.8
50.7
43.7
56.2
33.9
32
52.5
51.5
53.1
50.3
58.3
41.1
51.0
50.1
51.3
49.3
56.2
40.3
24
47.7
41.2
53.2
31.0
59.0
20.6
46.0
40.4
51.2
30.2
56.9
19.8
9945
27
48.8
47.9
53.1
39.3
59.0
28.9
47.4
46.5
51.2
38.5
56.8
28.1
29
51.2
50.3
53.2
46.1
58.9
35.8
49.7
48.8
51.3
45.3
56.8
35.0
32
53.7
52.7
53.9
52.1
58.9
42.6
52.1
51.1
52.2
50.9
56.7
41.9
24
48.2
42.6
53.7
31.8
59.5
20.8
46.5
41.7
51.7
31.0
57.3
20.0
10710
27
49.8
48.8
53.6
40.6
59.5
29.6
48.2
47.3
51.6
39.8
57.3
28.8
29
52.2
51.2
53.7
47.7
59.4
36.9
50.7
49.7
51.8
46.9
57.2
36.1
32
54.7
53.7
54.8
53.5
59.4
44.1
53.1
52.1
53.1
52.1
57.2
43.4
24
48.7
43.8
54.1
32.5
60.0
21.0
47.0
43.0
52.1
31.8
57.7
20.2
11475
27
50.6
49.6
54.0
41.8
59.9
30.2
49.0
48.1
52.0
41.0
57.7
29.5
29
53.1
52.1
54.3
49.2
59.9
37.9
51.5
50.5
52.3
48.4
57.6
37.2
32
55.7
54.6
55.6
54.6
59.8
45.6
54.0
53.0
53.9
52.9
57.6
44.8
Table PD-15 — Gross Cooling Capacities SRVE-150 (Cont.)
Metric
Ambient Temperature (°C)
40.5
46
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
16.0
19.5
23.0
DB
m3/h
(ºC)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
24
43.7
38.2
48.7
28.6
54.1
18.9
41.9
37.3
46.7
27.8
51.9
18.1
9180
27
44.9
44.1
48.7
36.4
54.1
26.7
43.4
42.5
46.6
35.6
51.8
25.9
29
47.2
46.3
48.8
42.8
54.0
33.1
45.6
44.7
46.8
41.9
51.8
32.4
32
49.4
48.5
49.5
48.2
54.0
39.6
47.8
46.9
47.7
46.8
51.7
38.8
24
44.2
39.6
49.2
29.4
54.6
19.1
42.4
38.7
47.3
28.6
52.3
18.3
9945
27
45.8
45.0
49.2
37.7
54.6
27.4
44.2
43.4
47.1
36.9
52.3
26.6
29
48.1
47.2
49.3
44.4
54.5
34.3
46.5
45.6
47.3
43.5
52.2
33.5
32
50.5
49.5
50.4
49.5
54.5
41.1
48.7
47.8
48.7
47.8
52.2
40.3
24
44.7
40.9
49.6
30.2
55.1
19.3
42.9
39.9
47.5
29.4
52.7
18.5
10710
27
46.6
45.8
49.6
39.0
55.0
28.1
45.0
44.2
47.5
38.2
52.6
27.3
29
49.0
48.1
49.8
46.0
55.0
35.3
47.3
46.4
47.8
44.9
52.6
34.6
32
51.4
50.4
51.4
50.4
54.9
42.6
49.6
48.7
49.6
48.7
52.6
41.8
24
45.1
42.1
50.0
31.0
55.4
19.4
43.3
41.0
47.8
30.1
53.0
18.7
11475
27
47.4
46.5
49.9
40.2
55.4
28.7
45.7
44.8
47.8
39.4
53.0
27.9
29
49.8
48.9
50.3
47.4
55.3
36.4
48.0
47.1
48.3
46.3
53.0
35.6
32
52.2
51.3
52.2
51.2
55.3
44.0
50.4
49.5
50.4
49.5
53.0
43.2
Notes:
TGC = Total Gross Capacity (kW)
SHC = Sensible Heat Capacity (kW)
