Trane Genius PKG-PRC007-EN - Manual (Page 26)

PKG-PRC007-EN 26
Table PD-11 — Gross Cooling Capacities SRVE-050 English
Ambient Temperature (°F)
85 95
Entering Wet Bulb Temperature (°F)
Ent. 61 67 73 61 67 73
DB
CFM (ºF) TGC SHC TGC SHC TGC SHC TGC SHC TGC SHC TGC SHC
75 53.7 44.2 60.2 34.1 67.1 23.9 52.2 43.5 58.4 33.4 65.1 23.1
1800 80 54.1 52.0 60.1 42.4 67.0 32.1 52.6 51.2 58.4 41.7 65.1 31.4
85 56.0 56.0 60.1 49.2 67.0 38.9 54.6 54.6 58.3 48.4 65.0 38.2
90 58.6 58.6 60.2 55.8 66.9 45.7 57.2 57.2 58.5 54.9 65.0 44.9
75 54.4 45.7 61.0 35.0 67.8 24.1 52.8 44.9 59.0 34.2 64.6 23.4
1950 80 54.9 53.7 60.8 43.8 67.7 32.9 53.4 52.8 59.0 42.9 65.7 32.1
85 57.2 57.2 60.8 51.0 67.7 40.1 55.9 55.9 58.9 50.2 65.7 39.3
90 60.0 60.0 61.2 57.9 67.6 47.3 58.5 58.5 59.4 56.9 65.6 46.5
75 55.0 47.2 61.5 35.8 68.5 24.3 53.3 46.4 59.7 35.1 66.5 23.6
2100 80 55.8 55.3 61.5 45.1 68.4 33.5 54.3 54.2 59.6 44.3 66.4 32.8
85 58.4 58.4 61.4 52.7 68.4 41.1 57.0 57.0 59.6 51.9 66.3 40.4
90 61.2 61.2 61.9 59.7 68.3 48.8 59.7 59.7 60.2 58.7 66.3 48.0
75 55.5 48.5 62.0 36.6 69.1 24.5 53.8 47.8 60.2 35.8 67.0 23.7
2250 80 56.6 56.6 62.0 46.3 69.0 34.2 55.2 55.2 60.1 45.6 66.9 33.5
85 59.5 59.5 62.0 54.4 68.9 42.3 58.0 58.0 60.1 53.5 66.9 41.6
90 62.3 62.3 62.6 61.4 71.3 50.2 60.8 60.8 61.0 60.3 66.8 49.5
Table PD-11 — Gross Cooling Capacities SRVE-050 (Cont.) English
Ambient Temperature (°F)
105 115
Entering Wet Bulb Temperature (°F)
Ent. 61 67 73 61 67 73
DB
CFM (ºF) TGC SHC TGC SHC TGC SHC TGC SHC TGC SHC TGC SHC
75 50.6 42.7 56.6 32.6 63.0 22.4 48.9 42.0 54.6 31.8 60.6 21.5
1800 80 51.1 50.2 56.5 40.8 63.0 30.5 49.5 49.2 54.5 40.1 60.6 29.8
85 53.3 53.3 56.5 47.7 62.9 37.4 51.8 51.8 54.5 46.9 60.5 36.6
90 55.8 55.8 56.7 54.1 62.9 44.1 54.3 54.3 54.9 53.0 60.5 43.2
75 51.1 44.2 57.1 33.5 63.6 22.6 49.4 43.4 55.1 32.6 61.3 21.7
1950 80 51.9 51.7 57.1 42.2 63.6 31.3 50.5 50.5 55.1 41.3 61.2 30.4
85 54.5 54.5 57.1 49.4 63.5 38.5 52.9 52.9 55.1 48.5 61.2 37.6
90 57.0 57.0 57.6 56.0 63.5 45.7 55.4 55.4 55.8 54.8 61.1 44.8
75 51.6 45.6 57.7 34.2 64.1 22.8 49.9 44.9 55.7 33.5 61.7 21.9
2100 80 52.9 52.9 57.7 43.5 64.1 32.0 51.4 51.4 55.5 42.7 61.7 31.2
85 55.5 55.5 57.7 51.1 64.0 39.6 54.0 54.0 55.7 50.2 61.6 38.8
90 58.2 58.2 58.4 57.6 64.0 47.3 56.5 56.5 56.5 56.3 61.6 46.3
75 52.2 47.0 58.2 35.1 64.7 23.0 50.4 46.1 56.1 34.2 62.2 22.2
2250 80 53.7 53.7 58.1 44.7 64.7 32.6 52.3 52.3 56.1 43.9 62.1 31.8
85 56.5 56.5 58.2 52.7 64.6 40.7 54.8 54.8 56.2 51.8 62.1 39.9
90 59.1 59.1 59.3 59.0 64.6 48.7 57.5 57.5 57.5 57.5 62.0 47.8
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Performance
Data Air Cooled
60 Hz
