Table PD-6 — Gross Cooling Capacities SAVE-050
English
ENT Water Temp (°F)
75
85
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
55.0
45.2
12.8
61.6
35.2
14.5
68.6
24.9
15.9
53.5
44.4
12.8
59.9
34.4
14.5
67.0
24.4
15.9
1800
80
55.2
53.1
12.8
61.5
43.4
14.5
68.6
33.1
15.9
53.7
52.3
12.8
59.9
42.6
14.5
66.8
32.4
15.9
85
56.7
57.8
13.2
61.5
50.1
14.5
68.5
39.8
15.9
55.4
56.5
13.2
59.8
49.4
14.1
66.8
39.2
15.9
90
59.2
60.4
14.1
61.5
56.7
14.5
68.5
46.5
15.9
58.0
59.1
14.1
59.9
56.0
14.5
66.7
45.9
15.9
75
55.7
46.6
13.2
62.3
36.0
14.5
69.4
25.2
15.9
54.1
45.9
13.2
60.7
35.3
14.5
67.7
24.6
15.9
1950
80
56.0
54.9
13.2
62.3
44.7
14.5
69.3
33.8
15.9
54.6
54.1
13.2
60.6
43.5
14.5
67.7
33.2
15.9
85
58.0
59.1
13.7
62.2
51.9
14.5
69.3
41.0
15.9
56.7
57.8
13.7
60.6
51.1
14.5
67.6
40.3
15.9
90
60.7
61.8
14.1
63.4
58.8
14.5
69.2
48.1
15.9
59.4
60.6
14.1
60.8
58.1
14.5
67.6
47.5
15.9
75
56.3
48.1
13.2
62.9
36.9
14.5
70.1
25.4
16.3
54.7
47.4
13.2
61.3
36.1
14.5
68.4
24.8
16.3
2100
80
56.9
56.6
13.7
62.9
46.0
14.5
70.0
34.5
16.3
55.4
55.7
13.2
61.3
45.3
14.5
68.3
33.9
15.9
85
59.1
60.3
14.1
62.8
53.6
14.5
70.0
42.1
16.3
57.9
59.0
14.1
61.2
52.8
14.5
68.3
41.5
15.9
90
61.9
63.1
14.5
63.1
60.8
14.5
69.9
49.7
16.3
60.7
61.8
14.5
61.6
60.0
14.5
68.2
49.0
15.9
75
56.9
49.5
13.7
63.5
37.6
15.0
70.8
25.6
16.3
55.2
48.7
13.2
61.9
37.0
14.5
69.0
25.0
16.3
2250
80
57.7
58.1
13.7
63.5
47.3
15.0
70.7
35.3
16.3
56.2
57.0
13.7
61.8
46.5
14.5
68.9
34.5
16.3
85
60.3
61.4
14.1
63.4
55.2
15.0
70.7
43.2
16.3
58.9
60.1
14.1
61.8
54.5
14.5
68.9
42.5
16.3
90
63.1
64.4
14.5
64.0
62.6
15.0
70.6
51.1
16.3
61.8
63.0
14.5
62.3
61.7
15.0
68.8
50.5
16.3
Table PD-6 — Gross Cooling Capacities SAVE-050 (Cont.)
ENT Water Temp (°F)
95
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
51.9
43.7
12.8
58.3
33.7
14.1
65.2
23.6
15.9
1800
80
52.2
51.5
12.8
58.2
41.9
14.1
65.1
31.8
15.9
85
54.2
55.2
13.7
58.2
48.6
14.1
65.1
38.5
15.9
90
56.8
57.9
14.1
58.3
55.2
14.1
65.0
45.3
15.9
75
52.5
45.2
13.2
59.0
34.5
14.5
65.9
23.8
15.9
1950
80
53.0
53.1
13.2
58.9
43.3
14.5
65.8
32.6
15.9
85
55.4
56.5
13.7
58.9
50.4
14.5
65.8
39.7
15.9
90
58.1
59.2
14.1
59.1
57.2
14.5
65.7
46.8
15.9
75
53.1
46.6
13.2
59.6
35.4
14.5
66.5
24.2
15.9
2100
80
54.0
54.6
13.7
59.5
44.5
14.5
66.5
33.3
15.9
85
56.5
57.6
14.1
59.5
52.2
14.5
66.4
40.8
15.9
90
59.3
60.5
14.5
59.9
59.1
14.5
66.4
48.3
15.9
75
53.7
48.0
13.2
60.2
36.2
14.5
67.2
24.4
16.3
2250
80
54.8
55.9
13.7
60.1
45.8
14.5
67.1
33.9
16.3
85
57.6
58.7
14.1
60.1
53.8
14.5
67.1
41.9
16.3
90
60.4
61.5
15.0
60.8
60.8
15.0
67.0
49.8
16.3
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Capacity Correction Factor Table
Delta T
Water
Total Cap.
Sens. Cap.
(°F)
GPM
MBh
MBh
4.5
2.21
1.01
1.01
7.2
1.39
1.01
1.01
10.0
1.00
1.00
1.00
12.6
0.79
0.99
1.00
15.3
0.66
0.99
1.00
18.0
0.56
0.98
0.99
Performance
Data
Water Cooled
60 Hz
