PKG-PRC007-EN 12
Performance
Data Fan
Data
Table PD-2 — Fan Performance SRVE/SIVE/SAVE 7.5 Tons
External static pressure with permanent air filter inches of water (Pa)
.08 .16 .24 .31 .39 .50
Model Airflow (19.9) (39.8) (59.8) (77.2) (97.1) (124.5)
Option 7.5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2703 4590 688 0.64 720 0.68 751 0.72 781 0.77 811 0.82 840 0.87
MT 1.5 CV 2815 4780 712 0.72 743 0.76 773 0.81 802 0.86 831 0.91 859 0.96
MS: 78,5 A 106,5 2927 4970 735 0.81 765 0.85 794 0.90 822 0.95 850 0.99 877 1.05
STD BS: 209 (9") 3041 5163 760 0.90 788 0.95 816 1.00 844 1.05 871 1.10
B: 1X A35 3154 5355 784 1.01 811 1.06 838 1.10 865 1.15
3267 5548 808 1.12 834 1.17 861 1.22
3380 5740 834 1.24 859 1.29
External static pressure with permanent air filter inches of water (Pa)
1.26 1.42 1.57
Model Airflow (313.7) (353.6) (390.9)
Option 7.5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP
2703 4590 1193 1.60
MT 3.0 CV 2815 4780 1159 1.61 1204 1.75
MS: 80 A 110 2927 4970 1171 1.74 1215 1.88
OP2 BS: 118 (5") 3041 5163 1184 1.86 1227 2.03
B: 1X B27 3154 5355 1198 2.01 1240 2.17
3267 5548 1169 1.97 1211 2.16 1253 2.34
3380 5740 1185 2.15 1227 2.32 1268 2.50
MT = Motor (CV).
MS = Motor Sheave, variable pitch (mm).
FS = Fan Sheave (mm).
B
= Belt.
External static pressure with permanent air filter inches of water (Pa)
.24 .31 .39 .50 .63 .79 .94 1.10 1.26 1.42
Model Airflow (59.8) (77.2) (97.1) (124.5) (156.9) (196.7) (234.1) (273.9) (313.7) (353.6)
Option 7.5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2703 4590 896 0.97 950 1.08 1002 1.19 1052 1.30 1100 1.41 1147 1.51
MT 2.0 CV 2815 4780 913 1.06 966 1.17 1017 1.28 1066 1.39 1113 1.50
MS: 78,5 A 106,5 2927 4970 931 1.16 982 1.26 1031 1.37 1079 1.49 1126 1.60
OP1 BS: 159 (7") 3041 5163 897 1.15 949 1.25 999 1.36 1047 1.47 1094 1.59 1140 1.72
B: 1X A32 3154 5355 891 1.21 917 1.26 968 1.36 1016 1.47 1064 1.59 1110 1.71 1154 1.83
3267 5548 886 1.27 912 1.32 937 1.37 986 1.47 1034 1.58 1080 1.70 1125 1.83
3380 5740 885 1.34 910 1.39 935 1.44 959 1.49 1007 1.59 1053 1.70 1098 1.83 1142 1.96
