Performance
Data
Water Cooled
60 Hz
Table PD-9 — Gross Cooling Capacities SAVE-125
Metric
ENT Water Temp (°C)
24.0
29.5
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
16.0
19.5
23.0
DB
m3/h
(°C)
TGC
SHC
l/s
TGC
SHC
l/s
TGC
SHC
l/s
TGC
SHC
l/s
TGC
SHC
l/s
TGC
SHC
l/s
24
39.8
32.2
1.97
44.5
25.0
2.17
49.6
17.7
2.39
38.6
31.6
1.97
43.2
24.5
2.17
48.2
17.1
2.36
7650
27
39.9
37.9
2.00
44.4
30.9
2.17
49.5
23.5
2.39
38.8
37.3
1.97
43.2
30.3
2.17
48.1
23.0
2.36
29
41.0
41.0
2.03
44.4
35.7
2.17
49.5
28.4
2.39
40.1
40.1
2.03
43.1
35.1
2.17
48.1
27.8
2.36
32
42.9
42.9
2.11
44.4
40.5
2.17
49.4
33.2
2.39
42.0
42.0
2.11
43.2
39.9
2.17
48.1
32.7
2.36
24
40.2
33.3
2.00
45.0
25.6
2.20
50.2
17.8
2.42
39.0
32.7
2.00
43.7
25.0
2.20
48.7
17.3
2.39
8285
27
40.5
39.2
2.00
45.0
31.8
2.20
50.1
24.0
2.42
39.3
38.5
2.00
43.7
31.4
2.20
48.7
23.5
2.39
29
42.0
42.0
2.06
44.9
37.0
2.20
50.1
29.2
2.42
41.0
41.0
2.06
43.6
36.4
2.20
48.6
28.6
2.39
32
43.9
43.9
2.14
45.0
42.0
2.20
50.0
34.3
2.42
42.9
42.9
2.14
43.8
41.3
2.20
48.6
33.8
2.39
24
40.7
34.3
2.03
45.5
26.2
2.22
50.6
18.0
2.45
39.5
33.7
2.00
44.1
25.6
2.20
49.2
17.5
2.42
8920
27
41.1
40.3
2.03
45.4
32.7
2.22
50.6
24.6
2.45
40.0
39.5
2.03
44.1
32.2
2.20
49.1
24.0
2.42
29
42.8
42.8
2.11
45.4
38.2
2.22
50.6
30.0
2.45
41.8
41.8
2.11
44.1
37.6
2.20
49.1
29.4
2.42
32
44.9
44.9
2.20
45.6
43.3
2.22
50.5
35.4
2.42
43.8
43.8
2.20
44.4
42.7
2.22
49.1
34.9
2.42
24
41.1
35.2
2.03
45.9
26.7
2.22
51.1
18.2
2.45
39.8
35.0
2.03
44.5
26.2
2.22
49.6
17.6
2.45
9560
27
41.2
41.0
2.06
45.8
33.7
2.22
51.0
25.0
2.45
40.6
40.4
2.06
44.5
33.1
2.22
49.6
24.5
2.45
29
43.6
43.6
2.14
45.8
39.3
2.22
51.0
30.7
2.45
42.5
42.5
2.14
44.5
38.8
2.22
49.5
30.2
2.45
32
45.7
45.7
2.22
46.2
44.6
2.25
51.0
36.4
2.45
44.6
44.6
2.22
44.9
43.9
2.25
49.5
35.9
2.45
Table PD-9 — Gross Cooling Capacities SAVE-125 (Cont.)
ENT Water Temp (°C)
35.0
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
DB
m3/h
(°C)
TGC
SHC
l/s
TGC
SHC
l/s
TGC
SHC
l/s
24
37.4
31.0
1.97
41.9
23.9
2.14
46.7
16.6
2.36
7650
27
37.6
36.6
1.97
41.8
29.7
2.14
46.7
22.5
2.36
29
39.1
39.1
2.03
41.8
34.6
2.14
46.6
27.3
2.36
32
40.9
40.9
2.11
41.9
39.3
2.17
46.6
32.1
2.36
24
37.8
32.1
1.97
42.3
24.5
2.17
47.2
16.8
2.39
8285
27
38.9
37.7
2.00
42.3
30.7
2.17
47.2
23.0
2.39
29
40.0
40.0
2.08
42.2
35.8
2.17
47.2
28.1
2.39
32
41.9
41.9
2.17
42.5
40.6
2.20
47.1
33.2
2.39
24
38.2
33.1
2.00
42.8
25.1
2.20
47.7
17.0
2.39
8920
27
38.9
38.7
2.03
42.7
31.6
2.20
47.6
23.5
2.39
29
40.7
40.7
2.11
42.7
37.0
2.20
47.6
28.9
2.39
32
42.7
42.7
2.20
43.1
41.9
2.20
47.5
34.3
2.39
24
38.5
34.1
2.03
43.1
25.6
2.20
48.1
17.1
2.42
9560
27
39.5
39.4
2.06
43.1
32.5
2.20
48.0
24.0
2.42
29
41.5
41.5
2.14
43.1
38.2
2.20
48.0
29.7
2.42
32
43.5
43.5
2.22
47.3
43.1
2.22
48.0
35.3
2.42
Notes:
TGC = Total Gross Capacity (kW)
SHC = Sensible Heat Capacity (kW)
Capacity Correction Factor Table
Delta T
Water
Total Cap.
Sens. Cap.
(°C)
l/s
kW
kW
2.5
2.21
1.01
1.01
4.0
1.39
1.01
1.01
5.5
1.00
1.00
1.00
7.0
0.79
0.99
1.00
8.5
0.66
0.99
1.00
10.0
0.56
0.98
0.99
