13 PKG-PRC007-EN
Table PD-3 — Fan Performance SRVE/SIVE/SAVE 10 Tons
External static pressure with permanent air filter inches of water (Pa)
.08 .16 .24 .31 .39
Model Airflow (19.9) (39.8) (59.8) (77.2) (97.1)
Option 10 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3604 6120 839 0.84 875 0.89 911 0.94 945 1.00 979 1.07
MT 1.5 CV 3754 6375 866 0.94 902 0.99 936 1.05 969 1.11 1002 1.17
MS: 78,5 A 106,5 3905 6630 895 1.04 929 1.10 963 1.16 995 1.23
STD BS: 184 (8") 4055 6885 924 1.16 957 1.22 989 1.28
B: 1X A35 4205 7140 954 1.29 986 1.35
4355 7395 984 1.42
4505 7650
External static pressure with permanent air filter inches of water (Pa)
.08 .16 .24 .31 .39 .50 .63 .79 .94 1.10 1.26
Model Airflow (19.9) (39.8) (59.8) (77.2) (97.1) (124.5) (156.9) (196.7) (234.1) (273.9) (313.7)
Option 10 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3604 6120 1012 1.13 1075 1.26 1136 1.41 1195 1.55 1252 1.71 1307 1.87
MT 2.0 CV 3754 6375 1034 1.24 7096 1.38 1156 1.53 1213 1.68 1269 1.83
MS: 78,5 A 106,5 3905 6630 1027 1.29 1058 1.36 1118 1.51 1176 1.66 1232 1.81
OP1 BS: 133 (6") 4055 6885 1021 1.35 1051 1.42 1082 1.49 1140 1.64 1197 1.79
B: 1X A31 4205 7140 1017 1.42 1048 1.49 1078 1.56 1107 1.63 1164 1.78
4355 7395 1015 1.49 1045 1.55 1075 1.63 1104 1.70 1132 1.77
4505 7650 1013 1.56 1043 1.63 1072 1.70 1101 1.77 1130 1.84 1157 1.92
External static pressure with permanent air filter inches of water (Pa)
.63 .79 .94 1.10 1.26 1.42 1.57
Model Airflow (156.9) (96.7) (234.1) (273.9) (313.7) (353.6) (390.9)
Option 10 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3604 6120 1360 2.01 1412 2.16
MT 3.0 CV 3754 6375 1322 1.98 1375 2.14 1425 2.29
MS: 80 A 110 3905 6630 1287 1.97 1340 2.12 1391 2.28 1441 2.43
OP2 BS: 118 (5") 4055 6885 1252 1.94 1305 2.10 1357 2.26 1407 2.42 1456 2.57
B: 1X B31 4205 7140 1220 1.93 1273 2.08 1325 2.24 1376 2.40 1425 2.56 1473 2.71
4355 7395 1188 1.92 1242 2.07 1295 2.23 1346 2.39 1395 2.54 1444 2.71
4505 7650 1212 2.06 1265 2.22 1316 2.37 1366 2.53 1414 2.69
MT = Motor (CV).
MS = Motor Sheave, variable pitch (mm).
FS = Fan Sheave (mm).
B
= Belt.
Performance
Data Fan
Data
