Table PD-5 — Fan Performance SRVE/SIVE/SAVE 15 Tons
External static pressure with permanent air filter inches of water (Pa)
.08 .16 .24 .31 .39 .50
Model Airflow (19.9) (39.8) (59.8) (77.2) (97.1) (124.5)
Option 15 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5406 9180 664 1.22 696 1.30 728 1.38 759 1.48 789 1.57 818 1.66
MT 3.0 CV 5632 9563 686 1.36 717 1.45 747 1.54 777 1.64 806 1.73
MS: 79 A 105 5857 9945 707 1.52 737 1.61 766 1.71 795 1.81
STD FS: 219 (9") 6080 10323 728 1.69 757 1.79 785 1.89 813 1.99
B: 1X B35 6302 10700 749 1.88 777 1.98 804 2.08
6530 11088 771 2.08 798 2.19
6758 11475 793 2.30
External static pressure with permanent air filter inches of water (Pa)
.16 .24 .31 .39 .50 .63 .79 .94 1.10 1.26
Model Airflow (39.8) (59.8) (77.2) (97.1) (124.5) (156.9) (196.7) (234.1) (273.9) (313.7)
Option 7.5 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5406 9180 875 1.87 930 2.08 983 2.30 1033 2.52 1082 2.74
MT 4.0 CV 5632 9563 835 1.83 890 2.03 944 2.25 995 2.47 1045 2.69
MS: 79 A 105 5857 9945 824 1.91 852 2.01 906 2.21 958 2.43 1008 2.65 1057 2.87
OP1 FS: 169 (7") 6080 10323 841 2.09 868 2.19 921 2.40 972 2.61 1021 2.83 1069 3.06
B: 1X B31 6302 10700 832 2.19 858 2.28 885 2.39 936 2.59 986 2.80 1034 3.02
6530 11088 825 2.29 851 2.40 877 2.50 903 2.60 953 2.81 1002 3.02 1049 3.24
6758 11475 819 2.41 845 2.52 871 2.62 896 2.72 921 2.85 970 3.03 1017 3.23 1064 3.46
External static pressure with permanent air filter inches of water (Pa)
1.10 1.26 1.42 1.57
Model Airflow (273.9) (313.7) (353.6) (390.9)
Option 15 TR CFM (m3/h) RPM BHP RPM BHP RPM BHP RPM BHP
5406 9180 1130 2.95 1176 3.17
MT 5.0 CV 5632 9563 1093 2.91 1140 3.13 1185 3.37
MS: 79 A 105 5857 9945 1104 3.10 1150 3.33 1194 3.58
OP2 FS: 143 (6") 6080 10323 1115 3.29 1160 3.53 1204 3.80
B: 1X B29 6302 10700 1081 3.26 1126 3.50 1171 3.77 1214 4.02
6530 11088 1095 3.48 1139 3.74 1183 4.00 1225 4.27
6758 11475 1108 3.71 1152 4.00 1195 4.20 1236 4.45
MT = Motor (CV).
MS = Motor Sheave, variable pitch (mm).
FS = Fan Sheave (mm).
B
= Belt.
