Table PD-8 — Gross Cooling Capacities SAVE-100
English
ENT Water Temp (°F)
75
85
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
109.9
87.9
26.0
122.7
68.5
28.6
136.6
48.7
31.7
106.7
86.3
26.0
119.5
67.1
28.6
133.2
47.5
31.3
3600
80
110.1
103.3
26.0
122.6
84.1
28.6
136.5
64.4
31.7
107.1
101.7
26.0
119.4
82.7
28.6
133.1
63.1
31.3
85
112.7
112.7
26.9
122.5
97.1
28.6
136.4
77.4
31.7
110.1
110.1
26.9
119.3
95.8
28.6
133.0
76.1
31.3
90
117.7
117.7
27.8
122.5
110.0
28.6
136.3
90.3
31.7
115.3
115.3
27.8
119.3
108.6
28.6
132.9
89.0
31.3
75
111.2
90.7
26.4
124.2
70.1
29.1
138.2
49.2
31.7
108.0
89.2
26.4
120.9
68.7
29.1
134.7
47.9
31.7
3900
80
111.8
106.8
26.4
124.1
86.7
29.1
138.0
65.8
31.7
108.8
105.1
26.4
120.7
85.3
29.1
134.6
64.6
31.7
85
115.3
115.3
27.3
124.0
100.5
29.1
137.9
79.6
31.7
112.7
112.7
27.3
120.7
99.1
29.1
134.5
78.3
31.7
90
120.5
120.5
28.2
124.1
114.0
29.1
137.8
93.3
31.7
117.9
117.9
28.2
120.9
112.5
29.1
134.4
92.0
31.7
75
112.5
93.4
26.9
125.6
71.7
29.5
139.6
49.6
32.2
109.3
91.9
26.4
122.2
70.2
29.1
136.1
48.4
32.2
4200
80
113.3
110.1
26.9
125.5
89.2
29.5
139.5
67.2
32.2
110.3
108.2
26.9
122.1
87.9
29.1
136.0
65.9
32.2
85
117.6
117.6
27.8
125.3
103.8
29.5
139.4
81.7
32.2
114.9
114.9
27.8
122.0
102.4
29.1
135.9
80.4
31.7
90
123.0
123.0
28.6
125.7
117.8
29.5
139.3
96.2
32.2
120.4
120.4
28.6
122.5
116.3
29.5
135.8
94.9
31.7
75
113.6
96.0
26.9
126.7
73.1
29.5
140.8
50.1
32.6
110.3
94.6
26.9
123.3
71.8
29.5
137.3
48.7
32.2
4500
80
114.8
113.0
27.3
126.6
91.7
29.5
140.7
68.5
32.6
111.9
110.9
27.3
123.2
90.2
29.5
137.2
67.3
32.2
85
119.7
119.7
28.2
126.5
106.9
29.5
140.6
83.7
32.2
117.0
117.0
28.2
123.1
105.6
29.5
137.1
82.5
32.2
90
125.2
125.2
29.5
127.2
121.3
29.5
140.5
99.0
32.2
122.6
122.6
29.5
124.0
119.7
29.5
137.0
97.7
32.2
Table PD-8 — Gross Cooling Capacities SAVE-100 (Cont.)
ENT Water Temp (°F)
95
Entering Wet Bulb Temperature (°F)
Ent.
61
67
73
DB
CFM
(°F)
TGC
SHC
GPM
TGC
SHC
GPM
TGC
SHC
GPM
75
103.6
84.9
26.0
116.1
65.6
28.6
129.7
46.1
31.3
3600
80
104.1
100.0
26.0
116.0
81.4
28.6
129.6
61.8
31.3
85
107.6
107.6
26.9
115.9
94.3
28.6
129.5
74.8
31.3
90
112.7
112.7
27.8
116.1
107.0
28.6
129.4
87.7
31.3
75
105.0
87.7
26.4
117.5
67.3
29.1
131.1
46.7
31.7
3900
80
105.8
103.3
26.4
117.4
83.9
28.6
131.0
63.2
31.7
85
110.1
110.1
27.3
117.3
97.6
28.6
130.9
76.9
31.7
90
115.3
115.3
28.2
117.7
110.9
29.1
130.8
90.6
31.7
75
106.1
90.3
26.4
118.8
68.8
29.1
132.5
47.1
31.7
4200
80
107.3
106.2
26.9
118.6
86.4
29.1
132.4
64.6
31.7
85
112.3
112.3
27.8
118.6
100.9
29.1
132.3
79.1
31.7
90
117.6
117.6
29.1
119.3
114.5
29.1
132.2
93.5
31.7
75
107.0
93.0
26.9
119.8
70.4
29.5
133.6
47.5
32.2
4500
80
109.0
108.7
27.3
119.7
88.8
29.5
133.5
65.9
32.2
85
114.3
114.3
28.2
119.6
104.1
29.5
133.4
81.2
32.2
90
119.9
119.9
29.5
120.7
117.8
29.5
133.3
96.4
32.2
Notes:
TGC = Total Gross Capacity (MBh)
SHC = Sensible Heat Capacity (MBh)
Capacity Correction Factor Table
Delta T
Water
Total Cap.
Sens. Cap.
(°F)
GPM
MBh
MBh
4.5
2.21
1.01
1.01
7.2
1.39
1.01
1.01
10.0
1.00
1.00
1.00
12.6
0.79
0.99
1.00
15.3
0.66
0.99
1.00
18.0
0.56
0.98
0.99
Performance
Data
Water Cooled
60 Hz
