Performance
Data
Air Cooled
60 Hz
Table PD-14 — Gross Cooling Capacities SRVE-125
Metric
Ambient Temperature (°C)
29.5
35.0
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
16.0
19.5
23.0
DB
m3/h
(ºC)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
24
38.6
31.7
43.1
24.5
48.0
17.1
37.3
32.4
41.7
23.9
46.3
16.5
7650
27
38.8
37.4
43.0
30.4
47.9
22.9
37.6
36.7
41.6
29.8
46.3
22.4
29
40.1
40.1
43.0
35.3
47.8
27.8
39.1
39.1
41.6
34.7
46.3
27.3
32
42.0
42.0
43.1
40.0
47.8
32.7
40.9
40.9
41.7
39.3
46.2
32.1
24
39.1
32.8
43.6
25.1
48.4
17.2
37.8
32.2
42.1
24.4
46.8
16.6
8285
27
39.4
38.6
43.5
31.3
48.4
23.5
38.2
37.8
42.1
30.7
46.8
22.9
29
41.0
41.0
43.5
36.5
48.4
28.6
39.9
39.9
42.1
35.9
46.7
28.0
32
43.0
43.0
43.7
41.5
48.3
33.8
41.8
41.8
42.3
40.7
46.7
33.2
24
39.5
33.9
44.0
25.7
48.9
17.4
38.1
33.2
42.5
25.1
47.2
16.8
8920
27
40.0
39.7
44.0
32.2
48.9
24.0
38.9
38.7
42.5
31.6
47.2
23.4
29
41.8
41.8
43.9
37.7
48.8
29.4
40.7
40.7
42.5
37.1
47.1
28.9
32
43.8
43.8
44.3
42.8
48.8
34.9
42.6
42.6
42.9
42.0
47.1
34.3
24
39.8
34.8
44.4
26.2
49.3
17.5
38.5
34.2
42.9
25.6
47.6
16.9
9560
27
40.6
40.5
44.4
33.2
49.2
24.5
39.4
39.4
42.8
32.6
47.5
23.9
29
42.5
42.5
44.4
38.9
49.2
30.2
41.4
41.4
42.9
38.3
47.5
29.6
32
44.6
44.6
44.8
43.9
49.2
36.1
43.4
43.4
43.5
43.1
47.5
35.3
Table PD-14 — Gross Cooling Capacities SRVE-125 (Cont.)
Metric
Ambient Temperature (°C)
40.5
46
Entering Wet Bulb Temperature (°C)
Ent.
16.0
19.5
23.0
16.0
19.5
23.0
DB
m3/h
(ºC)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
24
36.0
30.6
40.2
23.2
44.7
15.9
34.7
29.9
38.6
22.6
42.9
15.2
7650
27
36.4
35.9
40.2
29.2
44.6
21.8
35.2
35.0
38.6
28.5
42.9
21.1
29
38.0
38.0
40.1
34.0
44.6
26.6
36.8
36.8
38.6
33.4
42.8
26.0
32
39.8
39.8
40.3
38.6
44.6
31.5
38.5
38.5
38.9
37.8
42.8
30.9
24
36.4
31.6
40.6
23.9
45.1
16.0
35.0
30.9
39.0
23.2
43.3
15.4
8285
27
37.0
36.9
40.6
30.1
45.1
22.3
35.8
35.8
39.0
29.5
43.3
21.6
29
38.8
38.8
40.5
35.3
45.0
27.5
37.5
37.5
39.0
34.6
43.3
26.8
32
40.6
40.6
40.9
40.0
45.0
32.6
39.3
39.3
39.5
39.0
43.2
32.0
24
36.8
32.6
41.0
24.4
45.5
16.2
35.3
31.9
39.4
23.8
43.7
15.5
8920
27
37.6
37.6
41.0
31.1
45.4
22.8
36.4
36.4
39.3
30.4
43.6
22.1
29
39.5
39.5
41.0
36.5
45.4
28.3
38.2
38.2
39.4
35.8
43.6
27.6
32
41.4
41.4
41.5
41.1
45.4
33.7
40.1
40.1
40.1
39.9
43.6
33.0
24
37.1
33.5
41.3
25.0
45.8
16.3
35.7
32.8
39.7
24.3
44.0
15.7
9560
27
38.3
38.3
41.3
31.9
45.8
23.2
37.1
37.1
39.7
31.3
43.9
22.6
29
40.2
40.2
41.3
37.6
45.8
29.0
38.9
38.9
39.7
36.9
43.9
28.4
32
42.1
42.1
42.1
42.0
45.7
34.7
40.7
40.7
40.7
40.7
43.9
34.1
Notes:
TGC = Total Gross Capacity (kW)
SHC = Sensible Heat Capacity (kW)
