Repeat the editing procedure used to enter the 1st start time

andwater window.

8.

19

(Button to View)

5. Turn the Upper Line knob right to select water window duration.

1st Start/Window PRG A

Start 12:00am Win 16:00

(Button to View)

2nd Start/Window PRG A

Start 07:00pm Win 05:00

7. Turn the Upper Line knob right to select the 2nd Start Type screen.

The High ET start time option is Off by defualt. To program, turn the

Upper Line knob right to display the following setup screen.

Note:

Water window is the duration of time allotted for all stations,

assigned to the program to complete their programmed watering

cycle(s). The water window duration is adjustable from 1 hour to

23 hours and 59 minutes. The controller provides the water window

end time by factoring the selected start time and duration.

6. Turn the Lower Line knob to adjust number of hours, or turn the

Upper Line knob right to select minutes and edit as preferred.

Note:

A second program start time/water window is provided for

automatic syringe watering where compensation for higher than

normal ET is desired. Labeled High ET start, the controller

automatically reduces the total station watering amount during this

syringe operation to 25% of normal.
To prevent operational conflicts due to overlapping watering

cycles, the following setup criteria must be considered:
• The 2nd start time cannot occur within the 1st start time cycle
• The combined water window duration cannot exceed 23 hours

and 59 minutes.

If an Overlap condition alert is posted, the source of the conflict

must be resolved. If not corrected, the 2nd start time will default to

the Off mode. Press the Copy button to compare settings. Also

refer to the Alerts function on page 44 for additional information.
