TORO
APPROVED BACKFILL
TORO 570Z-2P SPRINKLER
LATERAL PIPE
SECTION/ELEVATION
NOT TO SCALE
d SELECT DESIRED OPTION
□
super
funny
pipe
□
swing
JOINT (SHOWN)
□
riser
TORO-IRRIGATION DIVISION
5825 JASMINE STREET
RIVERSIDE, CA 92504
TOLL FREE: 1-800-664-4740
PHONE: (951)785-3152
FAX: (951) 359-1870
MPR PLUS NOZZLE (SIZE PER PLAN)
MANUFACTURED SWING JOINT
LATERAL TEE
NOTES:
1. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURER’S SPECIFICATIONS.
2. DO NOT SCALE DRAWINGS.
3. INSTALL SPRINKLER AT FINISHED GRADE.
ST SPRINKLERS: 570Z SERIES 2" POP-UP
FIXED-SPRAY SPRINKLER, SWING JOINT
065-010
PROTECTED BY COPYRIGHT - 03/22/06
