TORO
LEGEND
TORO-IRRIGATION DIVISION
5825 JASMINE STREET
RIVERSIDE, CA 92504
TOLL FREE: 1-800-664-4740
PHONE: (951)785-3152
FAX: (951) 359-1870
1. MPR PLUS NOZZLE
(SIZE PER PLAN)
2. APPROVED BACKFILL
3. TORO 570Z-12P-SI-XX SPRINKLER
4. LATERAL PIPE
5. LATERAL TEE
6. MANUFACTURED
SWING JOINT
(i>
It
NOTE:
INSTALL SPRINKLER
AT FINISHED GRADE
SECTION/ELEVATION
NOT TO SCALE
NOTES:
1. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURERS SPECIFICATIONS.
2. DO NOT SCALE DRAWINGS.
3. CONTRACTORS NOTE: FOR PRODUCT AND COMPANY INFORMATION VISIT
REFERENCE NUMBER 065-009b.
570Z PRX SERIES
12 INCH POP-UP, XX - SI SPRINKLER (SWING JOINT)
065-009b
PROTECTED BY COPYRIGHT - 03/22/06
