TORO
TORO-IRRIGATION DIVISION
5825 JASMINE STREET
RIVERSIDE, CA 92504
TOLL FREE: 1-800-664-4740
PHONE: (951)785-3152
FAX: (951) 359-1870
FRONT
SECTION/ELEVATION
NOT TO SCALE
RIGHT-SIDE
SECTION/ELEVATION
MOTTO SCALE
NOTES:
1. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURERS SPECIFICATIONS.
2. DO NOT SCALE DRAWINGS.
3. CONTRACTORS NOTE: FOR PRODUCT AND COMPANY INFORMATION VISIT
REFERENCE NUMBER 065-098.
LT CONTROLLERS: E-SERIES OSMAC
PEDESTAL-MOUNT CONTROLLER, STAINLESS STEEL
065-098
PROTECTED BY COPYRIGHT - 03/22/06
