1. TMC OUTDOOR TORO CONTROLLER
MODEL NO TMC-212-OD
SEE IRRIGATION LEGEND FOR
NUMBER OF STATIONS
SECURE TO WALL WITH
APPROPRIATE FASTENERS.
2.1/2" CONDULET AND CONDUIT FOR
ELECTRICAL POWER PER LOCAL
AND NATIONAL ELECTRICAL CODES.
SECURE TO WALL WITH APPROPRIATE
PIPE CLAMPS
3. 1" CONDUIT FOR REMOTE CONTROL
WIRES. SECURE TO WALL WITH
APPROPRIATE PIPE CLAMPS
4. FINISHED GRADE
TORO-IRRIGATION DIVISION
5825 JASMINE STREET
RIVERSIDE, CA 92504
TOLL FREE: 1-800-664-4740
PHONE: (951)785-3152
FAX: (951) 359-1870
FRONT
SECTION/ELEVATION
NOT TO SCALE
RIGHT-SIDE
SECTION/ELEVATION
NOT TO SCALE
NOTES:
1. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURERS SPECIFICATIONS.
2. DO NOT SCALE DRAWINGS.
3. CONTRACTORS NOTE: FOR PRODUCT AND COMPANY INFORMATION VISIT
REFERENCE NUMBER 065-174a.
TMC-212 SERIES
EXTERIOR WALL-MOUNT CONTROLLER
065-174a
