Introduction _____________________________________________________________________
The 860S and 880S series full circle and adjustable part-circle rotary sprinklers
are designed specifically for golf course applications.
Manufactured from durable, high-strength engineering plastic and stainless-steel
components, the 800S series sprinklers incorporate many innovative and time-
proven features for lasting, maintenance-free operation.
Prior to installing the sprinkler, read through the recommended installation and
start-up procedures. Please observe all WARNINGS and CAUTIONS when
installing and operating this equipment.
Features ________________________________________________________________________
Specifications and Performance/Application Data ______________________________________
860S Series
■ Radius: 54'–80' (16.4 m–24.4 m)
■ Flow Rate: 14.1–44.5 GPM (44.3–155.9 l/mn)
■ Trajectory: 25°
■ Arc: Full Circle or Adjustable Part Circle (30°–330°)
■ Recommended Operating Pressure: 50–100 PSI (3.4–6.9 bar)
■ Minimum Pressure: 40 PSI (2.8 bar)
■ Maximum Pressure: 150 PSI (10.3 bar)
■ Precipitation Rate:
■ Minimum: 0.37"/hr (9.4 mm/hr)
■
Maximum: 0.75"/hr (19.1 mm/hr)
■ Body Height: 10" (25.4 cm)
■ Pop-Up Height: 3" (7.6 cm)
■ 1" NPT, BSP or ACME Female Thread Inlet
■ Spike Guard TM Solenoid:
■
24 V a.c., 50/60 Hz
■
Inrush Current: 50 Hz, 0.17 Amps (4.1 VA)
60 Hz, 0.12 Amps (2.9 VA)
■
Holding Current: 50 Hz, 0.15 Amps (3.6 VA)
60 Hz, 0.10 Amps (2.4 VA)
■ Manual Control: On-Off-Auto
■ Check-O-Matic model checks up to 37' (11.2 m) of elevation.
■ Color-coded Nozzles (see nozzle color code chart, p. 3)
880S Series
■ Radius: 53'–83' (16.2 m – 25.3 m)
■ Flow Rate: 14.3–52.9 GPM (54.1–200.2 l/mn)
■ Trajectory: 25°
■ Arc: Full Circle or Adjustable Part Circle 30°–330°
■ Recommended Operating Pressure: 50–100 PSI (3.4–6.9 bar)
■
Minimum Pressure: 40 PSI (2.8 bar)
■ Maximum Pressure: 150 PSI (10.3 bar)
■ Precipitation Rate:
■ Minimum: 0.39"/hr (9.9 mm/hr)
■
Maximum: 0.74"/hr (18.8 mm/hr)
■ Body Height: 11" (27.9 cm)
■ Pop-Up Height: 3" (7.6 cm)
■ 1.5" NPT, BSP or ACME Female Thread Inlet
■ Spike Guard TM Solenoid:
■
24 V a.c., 50/60 Hz
■
Inrush Current: 50 Hz, 0.17 Amps (4.1 VA)
60 Hz, 0.12 Amps (2.9 VA)
■
Holding Current: 50 Hz, 0.15 Amps (3.6 VA)
60 Hz, 0.10 Amps (2.4 VA)
■ Manual Control: On-Off-Auto
■ Check-O-Matic model checks up to 37' (11.2 m) of elevation.
■ Color-Coded Nozzles (see nozzle color code chart, p. 3)
860S Electric VIH 880S Electric VIH
■ Adjustable part-circle (30°–330°) and full circle models
available
■ Arc adjustment from top of sprinkler
■ Standard stainless-steel riser resists scoring from embedded
debris
■ Full 3" (7.6 cm) pop-up clears tall grasses
■ Nozzles color-coded by radius and gallonage
■ Cap serves as an effluent water indicator
■ Variable stator
■ Standard pressure regulation settings of 50 psi (3.4 bar),
65 psi (4.5 bar), 80 psi (5.5 bar) or 100 PSI (6.9 bar) to
ensure consistently accurate nozzle performance regardless
of elevation
■ Three body activation types available: Electric VIH,
Normally Open Hydraulic VIH, and Check-O-Matic
■ Three body thread types available: NPT, BSP and ACME
■ Manual control at the sprinkler, On-Off-Auto (Electric only)
■ Bowl-vented discharge (atmospheric) minimizes the
differential pressure required for regulation and ensures
positive valve closure (electric models only)
■ All internal components serviceable from the top of the
sprinkler
■ Large selection of color-coded nozzles available
■ Durable plastic and stainless-steel construction
■ Spike-Guard TM solenoid for superior surge protection
1
A U T O
O N
860S and 880S Series Rotary Sprinklers
Installation & Service Instructions
