TORO 34XX-10-XX SPRINKLER
APPROVED BACKFILL
LATERAL PIPE
NIPPLE
LATERAL TEE
SECTION/ELEVATION
NOT TO SCALE
DESIRED OPTION
dSELECT
□
super
FUNNY PIPE
□
swing
JOINT (SHOWN)
□
riser
NOTES:
1. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURER'S SPECIFICATIONS.
2. DO NOT SCALE DRAWINGS.
3. INSTALL SPRINKLER ABOVE FINISHED GRADE.
ST SPRINKLERS: 340 SERIES SHRUB
STREAM ROTOR SPRINKLER, SWING JOINT
PROTECTED BY COPYRIGHT - 03/22/06
