– 95 –
No. Part name
Side cabinet
Procedure
1. Side cabinet (right)
1) Perform step 1 in
‚
and all the steps in
ƒ
.
2) Remove the fixing screw (ST1TШ4 Ч 8L
5 pcs.) used for securing the side
cabinet to the bottom plate and valve
fixing panel.
2. Side cabinet (left)
1) Perform step 1 in
‚
.
2) Remove the fixing screw (ST1TШ4 Ч 8L
1 pcs.) used to secure the side cabinet
(left) onto the heat exchanger.
3) Remove the fixing screw (ST1TШ4 Ч 8L
2 pc.) used for securing the side cabinet
to the bottom plate and heat exchanger.
Remarks
A
B
C
The back body section is hooked
onto the bottom plate here.
Hook the claw onto
the bottom plate here.
Detail A Detail B Detail C
1) Perform work of item 1 of

and
‚
.
2) Remove the flange nut fixing the fan motor
and the propeller.
• Flange nut is loosened by turning clock-
wise. (To tighten the flange nut, turn
counterclockwise.)
3) Remove the propeller fan.
4) Disconnect the connector for fan motor
from the inverter.
5) Remove the fixing screws (2 pc.) holding
by hands so that the fan motor does not
fall.
* Precautions when assembling the fan
motor
Tighten the flange nut using a tightening
torque of 4.9 N•m.
Fan motor
Propeller fan
Flange nut
†
Fan motor
