11-9-2. P.C. Board Layout
GND
+12V
+5V
100
30
40
50
60
70
80
90
20
10
0
0 10 20 30 40 50
Resistance value (k
)
Temperature (˚C)
TD : Discharge temp. sensor
TA : Room temp. sensor
TC : Heat exchanger temp. sensor
TO : Outdoor temp. sensor
TE
: Outdoor heat exchanger temp. sensor
TS : Suction temp. sensor
TA, TC, TO, TE, TS
TD
[1] Sensor characteristic table
