– 5 –
2. SPECIFICATIONS
2-1. Specifications
RAS-B10GKVP-E/RAS-B13GKVP-E/RAS-B16GKVP-E, RAS-10GAVP-E/RAS-13GAVP-E/RAS-16GAVP-E
Indoor RAS-B10GKVP-E RAS-B13GKVP-E RAS-B16GKVP-E
Unit model
Outdoor RAS-10GAVP-E RAS-13GAVP-E RAS-16GAVP-E
Cooling capacity (kW) 2.5 3.5 4.5
Cooling capacity range (kW) 0.5–3.5 0.6–4.5 0.8–5.0
Heating capacity (kW) 3.2 4.2 5.5
Heating capacity range (kW) 0.6–5.8 0.6–6.6 0.8–7.8
Power supply 1 Ph/50Hz/220–240 V, 1 Ph/60Hz/220 V
Operation mode Cooling Heating Cooling Heating Cooling Heating
Running current (A) 0.15 0.15 0.15 0.15 0.15 0.15
Power consumption (W) 30 30 30 30 30 30
Indoor
Power factor (%) 87 87 87 87 87 87
Operation mode Cooling Heating Cooling Heating Cooling Heating
Running current (A) 2.48/2.37/2.26 3.25/3.10/2.96 4.25/4.06/3.89 4.52/4.31/4.13 6.45/6.17/5.90 7.07/6.76/6.47
Power consumption (W) 520 680 890 945 1350 1480
Power factor (%) 95 95 95 95 95 95
Electric
characteristics
Outdoor
Starting current (A) 3.40/3.25/3.11 4.67/4.46/4.28 7.22/6.91/6.62
COP (Cooling/Heating) 4.55/4.51 3.80/4.31 3.26/3.64
High (Cooling/Heating) (dB•A) 42/43 43/44 45/45
Medium (Cooling/Heating) (dB•A) 33/34 34/35 36/36 Indoor
Low (Cooling/Heating) (dB•A) 27/27 27/27 29/29
Operating
noise
Outdoor (Cooling/Heating) (dB•A) 46/47 48/50 49/50
Unit model RAS-B10GKVP-E RAS-B13GKVP-E RAS-B16GKVP-E
Height (mm) 250 250 250
Width (mm) 790 790 790 Dimension
Depth (mm) 215 215 215
Net weight (kg) 9 9 9
Fan motor output (W) 30 30 30
Indoor unit
Air flow rate (Cooling/Heating) (m³/h) 550/610 560/640 640/660
Unit model RAS-10GAVP-E RAS-13GAVP-E RAS-16GAVP-E
Height (mm) 550 550 550
Width (mm) 780 780 780 Dimension
Depth (mm) 290 290 290
Net weight (kg) 35 37 37
Motor output (W) 750 750 750
Type Twin rotary type with DC-inverter variable speed control Compressor
Model DA111A1F-20F1 DA111A1F-20F1 DA111A1F-20F1
Fan motor output (W) 43 43 43
Outdoor unit
Air flow rate (Cooling/Heating) (m³/h) 2150/2150 2410/2410 2410/2410
Type Flare connection Flare connection Flare connection
Liquid side Ш6.35 Ш6.35 Ш6.35
Indoor unit
Gas side Ш9.52 Ш9.52 Ш12.7
Liquid side Ш6.35 Ш6.35 Ш6.35
Outdoor unit
Gas side Ш9.52 Ш9.52 Ш12.7
Maximum length (m) 25 25 25
Maximum chargeless length (m) 15 15 15
Piping
connection
Maximum height difference (m) 10 10 10
Name of refrigerant R410A R410A R410A
Refrigerant
Weight (kg) 0.82 0.96 0.96
Power supply 3 Wires : includes earth (Outdoor) Wiring
connection
Interconnection 4 Wires : includes earth
Indoor (Cooling/Heating) (°C) 21–32/0–28 21–32/0–28 21–32/0–28
Usable temperature range
Outdoor (Cooling/Heating) (°C) 5–43/–15–24 5–43/–15–24 5–43/–15–24
Installation plate 1 1 1
Wireless remote controller 1 1 1
Batteries 2 2 2
Remote controller holder 1 1 1
Zeolite-plus filter 1 1 1
Mounting screw 6 (Ш4 Ч 25L) 6 (Ш4 Ч 25L) 6 (Ш4 Ч 25L)
Remote controller holder
mounting screw
2 (Ш3.1 Ч 16L) 2 (Ш3.1 Ч 16L) 2 (Ш3.1 Ч 16L)
Plasma pure filter 1 1 1
Installation manual 1 1 1
Indoor unit
Owner’s manual 1 1 1
Drain nipple 1 1 1
Accessory
Outdoor unit
Water-proof rubber cap 2 2 2
• The specifications may be subject to change without notice for purpose of improvement.
