General
Camera Parts
Specifications
Power Source Voltage Rechargeable Battery DB-43 (3.7 V) × 1
External (AC adapter): 3.8 V
AA Dry Alkaline Battery, Nickel-Hydrogen Battery
× 2
External Dimensions 133.0 mm (W) × 74.0 mm (H) × 78.5 mm (D) (excluding projecting parts)
Weight Camera: Approximately 430 g (excluding battery, strap)
Accessories: Approximately 50 g (battery, strap)
Tripod Hole Shape 1/4-20UNC
Operating Temperature Range -10 qC to 40 qC
Operating Humidity Range
85% or less
Storage Temperature Range -20 qC to 60 qC
Water Resistance JIS protection grade 7, IEC IP67
Dust Resistance JIS protection grade 6, IEC IP67
Image Pickup Element Total 8.30 million pixels (effective pixels 8.13 million), 1/1.8" primary-color
CCD
Lens
Lens
3.0 × Optical Zoom
Aperture: F2.5 (Wide-angle) to 4.3 (Telephoto)
Focal Length 5.8 to 17.4 mm (equivalent to 28 to 85 mm on a 35mm camera)
Shooting Distance Approximately 0.3 m to A (Wide-angle) or 1.0 m to A (Telephoto)
Macro Shooting Distance
(from the very front of the
camera) Approximately 0.005 m to A (Wide-angle), 0.1 m to A (Telephoto) or
0.005 m to A (Zoom macro mode)
Digital Zoom 4.0 times
Monitor Display Parts
Screen Size
2.5"
Type Transparent Amorphous Silicon TFT LCD
Pixel Count Approx. 150,000
White Balance AUTO/Fixed (OUTDOORS, CLOUDY, INCAND., INCAND.2, FLUORES.,
MANUAL)
Exposure Adjustment
Light Metering Sensitivity
Distribution
Multi Light Metering (256 segments), Center-weighted Light Metering, Spot
Metering
Exposure Compensation Manual exposure compensation +/-2.0EV (1/3EV Steps)
Metering Method TTL-CCD Metering Method
Flash AE Yes (In Daylight Synchro: On)
Shutter Still image: 8, 4, 2, 1 to 1/2000 seconds; Movie: 1/30 to 1/2000 seconds
ISO Sensitivity AUTO, ISO 64, ISO 100, ISO 200, ISO 400, ISO 800, ISO 1600
