Ricoh 500SE - Manual (Page 203)

200
10
U
s
in
g
th
e W
irel
ess
L
AN F
u
n
c
tio
n
(O
n
ly
fo
r Cap
lio
500S
E-W
)
(
*
)
The folder set in [Specify Folder] on the [FTP
Send] tab (GP.198) is the inbox folder.
Note ----------------------------------------------------------------------------------------------
The inbox folder is not created automatically. Create a folder with the same name as the
specified folder.
4
When [Server] or [Server+Camera] is selected in Step 3,
specify the inbox folder in the [Folder name] box.
• Click the folder icon to display a dialog box. You can select and specify
a folder here.
5
When necessary, specify a log file name in the [Log file
name] box.
• If a log file name is specified, a connection status log file is created. If
not, no log file is created.
• Specify a full path for the log file name.
• Click the folder icon to display a dialog box. You can select and specify
the folder name here.
6
Click [Apply].
• This completes the setup.
7
Click [Quit].
• Caplio Server closes.
