Various Settings
You can use the equalizer to modify the tonal character of the
sound by boosting or reducing just the low-frequency or high-
frequency range of the sound.
1. Hold down the [Effects] button and press the
[3D] button.
2. Use the [ ▲ ] [ ▼ ] buttons to select “Equalizer.”
3. Press the [ ] button.
The following appears in the display.
fig.d-EQ-Off.eps
4. Press the [+] button to select “On.”
fig.d-EQ-On.eps
5. Press the [ ] button.
The equalizer setting screen appears.
fig.d-EQ-Number.eps
6. Use the [
▲
] [
▼
] buttons to select an item.
fig.d-EQ-Param.eps
7. Use the [-] [+] buttons to change the setting
for the selected item.
The sound may distort if you raise the gain value. If so,
lower the master gain (p. 88).
Equalizer Settings
Changing the Equalizer Settings
(Equalizer)
Item Value Description
EQ Number 1–4
Selects a set of preset
equalizer settings.
High Gain -12–+12 dB
Adjusts the level of the high-
frequency range.
High Freq 1.25 k–16.0 k (Hz)
Frequency point in the high-
frequency range. Generally,
this changes the level at and
over this frequency.
High Mid
Gain
-12–+12 dB
Adjusts the level of the mid-
to high-frequency range.
High Mid
Freq
16–16.0 k (Hz)
Frequency point in the mid-
to high-frequency range to
midrange. This changes the
level of the specified
bandwidth centered on this
frequency.
High Mid Q
0.5, 1.0, 2.0, 4.0,
8.0
Changes the bandwidth of
the mid- to high-frequency
range. The bandwidth
affected by the controls
narrows as the value
increases.
Low Mid
Gain
-12–+12 dB
Adjusts the level of the low-
frequency range to
midrange.
Low Mid
Freq
16–16.0 k (Hz)
Frequency point in the low-
frequency range to
midrange. This changes the
level of the specified
bandwidth centered on this
frequency.
Low Mid Q
0.5, 1.0, 2.0, 4.0,
8.0
Changes the bandwidth of
the low-frequency range to
midrange. The bandwidth
affected by the controls
narrows as the value
increases.
Low Gain -12–+12 dB
Adjusts the level of the low-
frequency range.
Low Freq 100–1.0 k (Hz)
Frequency point in the low-
frequency range. Generally,
this changes the level at and
below this frequency.
NOTE
