67
Making Various Settings
Connecting the RG-1F/RG-3F to a V-LINK compatible image
device allows you to control the images with the RG-1F/RG-3F.
V-LINK
V-LINK ( ) is a function that allows music and
images to be performed together. By using MIDI to connect two
or more V-LINK compatible devices, you can easily enjoy
performing a wide range of visual effects that are linked to the
expressive elements of a music performance.
1. Press the [Piano Designer] button so the indicator is lit.
2. Use the [ ▲ ] [ ▼ ] buttons to select “8. MIDI.”
3. Press the [Enter] button.
4. Use the [ ▲ ] [ ▼ ] buttons to select “V-LINK.”
fig.d-MIDI-VLink.eps
5. Press the [+] or [–] button to switch the V-LINK function
on or off.
* This is set to “Off” when you turn on the power.
While V-LINK is switched on, no sound is produced
when you press any of the twelve keys at the left end of
the keyboard.
6. Press the [ ▼ ] button to select “V-LINK Channel.”
fig.d-MIDI-VLinkCh.eps
7. Use the [+] [–] buttons to specify the V-LINK transmit
channel.
8. Press the [Piano Designer] button several times to make
the indicator go dark.
If V-LINK is on, the V-LINK icon ( ) is shown in the
screen.
Using the V-LINK Function
Value Description
On
The V-LINK function is switched on.
You can control images using the twelve keys
at the left end of the keyboard.
Off The V-LINK function is switched off.
Value 1–16
