16
Getting Ready
Raising the music rest
Raise the music rest before you open the piano top. Close
the piano top before you lower the music rest.
1. Gently raise the music rest and fasten it in place.
2. To fold back the music rest, support it with your hand,
bend down the metal fixtures, and gently lower the
music rest into position.
fig.music-rest1_e.eps
Using the music supports (for the RG-3F)
By raising the music supports you can hold a music book open to
the desired page.
If you’re not using the music supports, fold them down.
fig.music-rest2_e.eps
Opening the top (for the RG-1F)
The top must be opened or closed by an adult.
3. Use both hands to firmly grasp the right side of the top
(toward the high notes: position A in the illustration),
and slowly raise it.
fig.LidOpen1_e.eps
When opening the top, take care not to open it too far. An
angle of about 30 degrees is appropriate. Opening the top
significantly beyond this angle may damage the piano, or
cause the top to fall. Before you open the top, make sure that
no one is in the direction toward which the top opens.
Do not transport the piano with the top opened. Doing so
may cause the top stick to come out of its socket, allowing
the top to fall.
4. Using one hand to support the top, raise the top stick
and fit it into its socket.
Opening/Closing the Top
(2)
(2)
(2)
(2)
(1)
Push
A
