NetWare 3.x - Advanced Settings

F Type a new name, if you change the name of the printer.

A name “Printer x” is assigned to the printer. x stands for the number of
the selected printer.

G Select [Remote Parallel, LPT1] for type.

The IRQ, Buffer size, Starting form, and Queue service mode are automat-
ically configured.

H Press the {{{{ESC}}}} key, and then click [Yes] in the confirmation dialog box.
I Press the {{{{ESC}}}} key to return to [Print Server Configuration Menu].

NNNN

Assign print queues to the created printer as follows:
A From [Print Server Configuration Menu], select [Queues Serviced By Printer].
B Select the printer created in step MMMM.
C Press the {{{{INSERT}}}} key to select a queue serviced by the printer.

Note

❒ You can select more than one queue at a time.

D Follow the instructions on the screen to make other necessary settings.

When you have finished the above steps, make sure that the queues are as-
signed.

OOOO

Press the

{{{{ESC}}}} key until “Exit?” appears, and then select [Yes] to exit

PCONSOLE.

PPPP

Start the print server by typing the following from the console of the Net-
Ware Server.
If it is running, restart it after exiting it.

❖

❖ To exit

CAREE: unload pserver

❖

❖ To start

CAREE: load pserver print_server_name

Note

❒ If the printer works as configured, “Waiting for job” appears.
