Memory Unit TypeB 64MB
19
2
GGGG
Place the controller board on a flat
surface.
HHHH
Insert the Memory unit to the slot
by placing the notch of the unit to
the projection of the slot, and
then push it down until it clicks.
IIII
Match the controller board to the
top and bottom rail using the "
T T T T"
mark, and then slide it into the
printer slowly until it stops.
JJJJ
Push the handle of the controller
board until it clicks.
KKKK
Fasten the controller board to the
printer with the two screws.
Note
❒ If the Duplex Unit is not at-
tached, go to step N .
LLLL
While aligning the power cord to
the left side groove of the Duplex
Unit, slide the Duplex Unit in un-
til it is connected to the printer.
MMMM
Attach the interface cable to the
printer.
ZGDX130J
ZGDX250J
ZGDX380J
ZGDX270J
ZGDX240J
