22
D
Turn the camera on.
The PC will automatically detect the equipment which has been connected and
operate accordingly. If a message is displayed, follow the instructions on the
screen.
Connection by USB cable is completed.
From this point you can connect or disconnect the camera and PC at any time
simply by inserting or removing the USB cable.
■ Connecting the Camera by Serial Cable (For Windows)
You can connect the camera to a PC running Windows using a special serial
cable.
Important
Note
• Make sure that both the PC and the camera are turned off before
connecting or disconnecting the serial cable.
A
Check that the PC and the camera are turned off.
B
Open the terminal cover on the right
side of the camera.
C
Insert the flat connector on one end
of the serial cable into the USB/AUX
terminal of the camera with the seal
facing up.
D
Insert the connector on the other end
of the cable into the serial terminal of
the PC.
Connection by serial cable is completed.
