Page 66
66
Dialing Plan configuration
This section describes the common call scenarios. The unique call
scenarios are described with the configuration of the corresponding option,
starting with
Normal Mode: Main office telephone calls an analog phone at the
SRG
The call is routed through the NRS and handled by the SRG.
13 "Normal Mode: Main office telephone calls an analog phone at the SRG"
(page 66)
shows how the call proceeds.
Figure 13
Normal Mode: Main office telephone calls an analog phone at the SRG
Normal Mode: Main office telephone calls a branch IP Phone
The call
is recognized as a main office number, and the call is directed to the SRG
IP telephone using internal routing at the main office.
Nortel Communication Server 1000
Main Office Configuration Guide for SRG 50
NN43001-307
02.02
Standard
Release 5.0
3 December 2007
Copyright © 2005-2007, Nortel Networks
.
