Feature implementation using element manager, Procedure 10 – Nortel Networks SRG 50 NN43001-307 User Manual
Page 178
178
Alternative Call Routing for Network Bandwidth Management
Feature implementation using Element Manager
Zone configuration
Use Element Manager to configure the specific zone properties.
1. Access the Zones web page to select Alternate Routing for Calls
between IP Stations.
2. Access the Alternate Routing for Calls between IP Stations web
page to configure the feature.
Accessing the Zones web page
Procedure 10
Accessing the Zones web page
Step
Action
1
From the navigator, click IP Network > Zones.
The Zones web page opens. See
Figure 72
Zones
2
Under Configuration click beside the Zone, or click the Zone you
are programming, to expand the choices under it.
3
Click Alternate Routing for Calls between IP Stations.
Nortel Communication Server 1000
Main Office Configuration Guide for SRG 50
NN43001-307
02.02
Standard
Release 5.0
3 December 2007
Copyright © 2005-2007, Nortel Networks
.
