IP Peer Networking configuration

For Trunk data block (TYPE), select IP Trunk (IPTI).

Type the Terminal Number (TN) for the trunk.

For Designator field for trunk (DES), type a meaningful value.

For Extended Trunk (XTRK), select Virtual trunk (VTRK).

Type the Route number, Member number (RTMB)for the trunk.

Set the values of Start arrangement Incoming (STRI) and Start
arrangement Outgoing (STRO).
Immediate (IMM) is recommended for both fields.

Type the Channel ID for this trunk (CHID).

You can add a Class of Service (CLS) for all features that you wish.
In a basic configuration, you can leave the CLS as is.

Select Advanced Trunk Configurations to display a list of
advanced features.

Edit the necessary fields or accept the default values.

Click Submit.

—End—

Creating the Network Control Block (NCTL) for network access (LD 87)

Complete the following procedure to create the Network Control Block.

Creating the Network Control Block (NCTL) for network access
(LD 87)

Step

Action

Log onto Element Manager.

Select Open Dialing and Numbering Plans > Electronic Switched
Networks.

Expand the Customer tab.
See

Figure 17 "Electronic Switched Network (ESN)" (page 47)

Select Network Control and Services > Network Control
Parameter (NTCL).
A message appears if no network control data is configured. Click
OK to configure new data.

Next to Network Control Basic Parameters, click the Edit tab.

Enterprise: Common
