100 NRS configuration
Field Value Description
Tandem Gateway endpoint
name string> The tandem Gateway is optional. This
indicates whether the endpoint is used to
tandem calls from outside the network. The
name must be alphanumeric and up to 30
characters in length.
Note: Use the Look-up link to find
configured Gateway endpoints.
Endpoint authentication
enabled Not configured
Authentication
off
Authentication
on
If this option is selected, the Gateway
endpoint uses the L1 or L0 authentication
(if enabled).
If this option is selected, authentication is
off for this Gateway endpoint even if L1 or
L0 authentication is enabled.
If this option is selected, authentication
is on for this Gateway endpoint, and the
authentication overrides the L1 or L0
authentication (if enabled).
Authentication password string> If Authentication on is selected, choose
a password. The password must be
alphanumeric and up to 30 characters in
length.
E.164 country code Optional. The code must be numeric and
up to 7 characters in length.
E.164 area code Optional. The code must be numeric and
up to 7 characters in length.
E.164 international dialing
access code Optional. The code must be numeric and
up to 7 characters in length.
E.164 national dialing access
code Optional. The code must be numeric and
up to 7 characters in length.
E.164 local (subscriber)
dialing access code Optional. The code must be numeric and
up to 7 characters in length.
Private L1 domain (UDP)
location) dialing access code Optional. The code must be numeric and
up to 7 characters in length.
Private special number 1 Optional. The number must be numeric
and up to 30 characters in length.
Private special number 2 Optional. The number must be numeric
and up to 30 characters in length.
Static endpoint address type IP version 4 Select IP version 4 from the drop-down list.
Static endpoint address address> This is the address of the MCS 5100
application server, responsible for the MCS
voice path. If a third-party Gateway is used,
it is the IP address of the Gateway.
