114 Appendix Integration example
Parameter Value
Session Initiation Protocol (SIP) Gateway
primary proxy/redirect IP address 192.167.105.2
Network Routing Service (NRS) primary IP
address 192.167.105.2
Signaling Server voice LAN (TLAN) 192.167.105.2
TLAN of the Signaling Server 192.167.105.3
Voice LAN (TLAN) node 192.167.105.3
MCS 5100 application server 192.168.248.13
MCS 5100 provisioning client 192.168.248.14/prov
Management LAN subnet mask 255.255.255.0
Voice LAN subnet mask 255.255.255.0
Gateway endpoint static IP addresses 192.167.104.3
192.168.248.13
Names
NRS host name 1000S_CP
L0 domain name cdp
L1 domain name udp
MCS 5100 domain name cdsig.com
Service domain cdsig.com
Signaling Server SIP domain name cdsig.com
Signaling Server H.323 ID CS1000S_CP
Signaling Server host name CS1000S_CP
Signaling Server SIP Gateway endpoint
name(s) CS1000S_CP
convergeddesktop
H.323 alias name CS1000NODE5
Terminal Numbers (TN)
Trunk TN(s) 65 0 00 00
65 0 00 01
PCA TN(s) 66 0 00 00
66 0 00 01
Converged Desktop set TN(s) 66 0 00 02
66 0 00 03
Directory Numbers (DN)
Special DN (SPN) 4330
Service DN used for making VTRK calls 4330
Default ACD DN (DFDN) 4330
Enterprise: Common
Solution Integration Guide for Communication Server 1000/Multimedia Communication Server 5100
NN49000-301 01.01 Standard
Release 4.5 27 October 2006
Copyright © 2006, Nortel Networks Nortel Networks Confidential
.
