Chapter 8 System Capacity LT/AP Card Slots
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 83
LT/AP Card Slots
Note 1:
The LT cards shall be installed according to the following conditions:
• Maximum number of ports per PIM: 64 ports
Note 2:
The AP cards shall be installed according to the following conditions:
• Maximum number of cards per system: 24 cards
• Maximum number of ports per system: 256 ports
Note 3:
When the system is comprised of more than two PIMs, vacant slots exist in Slot 12 (MP Slot) of PIM 1, 3,
5, and 7.
Table 8-3 Number of Slots for LT/AP Cards of each PIM
ITEM
MAXIMUM NUMBER
OF SLOTS USED FOR
LT AND AP CARDS
(SLOTS/SYSTEM)
NUMBER OF SLOTS OCCUPIED
BY CONTROL CARDS
(SLOTS/SYSTEM)
TOTAL
NUMBER
OF
SLOTS
SLOT NUMBER 00-11
TYPE OF CARD INSTALLED LT/AP MP FP/BUS
VACANT
SYSTEM
CONFIGURATION
1-PIM System
12
1
0
0
13
2-PIM System
24
1
0
1
26
3-PIM System
35
1
1
1
39
4-PIM System
47
1
1
2
52
5-PIM System
59
1
2
2
65
6-PIM System
71
1
2
3
78
7-PIM System
83
1
3
3
91
8-PIM System
95
1
3
4
104
