NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 79
Chapter 8 System Capacity
Main Processor (MP) System
Table 8-1 Main Processor (MP) System
ITEM
SYSTEM CAPACITY Note 1 , Note 2
1 PIM 2 PIM 3 PIM 4 PIM 5 PIM 6 PIM 7 PIM 8 PIM
(Number of Ports)
LT Card
(Number of Cards)
64 128 192 256 320 384 448 512
12 24 35 47 59 71 83 95
(Number of Ports)
AP Card
(Number of Cards)
Maximum 256 ports per system
12 24
Total Number of Lines (Analog Single-line Telephone +
Dterm)
64 128 192 256 320 384 448 512
IP PAD (Number of Channels) 64 128 192 256
Analog Single-line Telephone (Lines)
Standard 64 128 192 256 320 384 448 512
Long 24 48 72 96 120 144 168 192
Dterm
Standard 64 128 192 256 320 384 448 512
Long 24 48 72 96 120 144 168 192
Dterm IP (Peer-to-Peer Connection) Note 3 448 384 320 256 192 128 64 0
Dterm PS II 256
Zone Transceiver (ZT) 16 32 48 64 80 96 112 128
ISDN Station 16 32 48 64 80 96 112 128
Central Office Trunk (Lines)
Loop Start 64 128 192 256
DID with 4-DIT 48 96 144 192 240 256
Tie Line Trunk (Lines)
LDT 24 48 72 96 120 144 168 192
2-Wire E&M 24 48 72 96 120 144 168 192
4-Wire E&M 24 48 72 96 120 144 168 192
CCIS Trunk (Peer-to-Peer Connection) Maximum 255
DTI/CCIS Digital Link Note 1
1.5 M - AMI DTI: 10, CCIS: 8
2 M - AMI Maximum eight links per system
