Chapter 3 Module and Installation Hardware
Installation Hardware
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 27
Battery Module
(BATTM)
The BATTM is an optional module for installing optional long-term backup batteries.
These batteries provide backup protection for approximately three hours. The
BATTM is designed to accommodate batteries covering up to a 4-PIM system (two
BATTMs support maximum system configuration).
The BATTM is available for Floor-standing Installation. (When the system is a
Wall-mounting/19-inch Rack-mounting configuration, the BATTM cannot be
installed with the PIM.)
Note:
For the purpose of simplifying orders, a PIM includes AC/DC Power Card
and Power Cable.
Installation Hardware
Base/Top
Assembly
The Base/Top Assembly includes a Base Unit and a Top Cover for the PIM. One
Base/Top Assembly is required for each PIM stack.
Hanger Assembly
Hanger Assembly is used for Wall-mounting Installation. One set of Hanger
Assembly is required for each PIM. Refer to
for drawings of
Wall-mounting Installation.
19-inch Bracket
The 19-inch Bracket is a set of hardware used for 19-inch Rack-mounting Installation.
•
19-inch Rack Bracket (A) is installed at both sides of the PIM. One set of 19-inch
Bracket (A) is required for each PIM.
•
19-inch Rack Bracket (B) is installed at the base of stack. One set of 19-inch
Bracket (B) is required for each stack.
If the system contains two PIMs or more with 19-inch Bracket (B), one set of 19-inch
Bracket (A) is also required for the top PIM.
Refer to
and
for drawings of 19-inch Rack-mounting
Installation.
Optional Bracket
A Mounting Bracket is used for Floor-standing Installation. Without a Mounting
Bracket, 1.1 G shockproof is provided for a 1- to 3-PIM stack, and 0.5 G shockproof is
provided for a stack of four or more PIMs. To enhance the shockproof capability to
Table 3-1 Modules
ABBR.
NAME CODE
PART
NUMBER
REMARKS
PIMMD
SN1617 PIMMD
150018
PIM 0 ~ PIM 7
BATTM
SN1619 BATTMB
151120
One per stack.
Maximum of two per system.
