Chapter 4 Circuit Cards Application Processor (AP) Cards
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 51
Note:
The Expansion Memory is the on-board sub-memory card for the AP00-B. It provides additional memory
capacity as shown below.
Note:
The AP cards may be installed in Slot 00 to 11 of PIM 0-7, with the following conditions:
• Maximum 24 cards per system
• Maximum 256 ports per system
Remote
PIM
SPN-DAIA-C (AP)
SC-2553 SHS RPM PROG-CC
RMT BUS-0.6 CA-A
17-TW-0.3 CONN CA-A
151217 2
T1 Interface
• For Remote PIM at main system
• Maximum three cards per main site
SPN-DAIB (AP)
SC-2586 SHS RPM PROG-CD
151211 2
T1 Interface
• For Remote PIM at remote system
• One MP Slot per card
• Maximum one card per remote site
SPN-DAIC (AP)
48-TW-0.2 CONN CA
151212 2
T1 Interface
• For Remote PIM at main and remote
system.
• Used to expand Time Slot capacity of the
Remote PIM.
• Maximum of 12 cards per main site
• Maximum of two cards per remote site
Wireless
Roaming
SPN-AP00B DBM (AP)
SC-2972 IXS DBM PROG-A1
151230 2
Database Memory
• For Wireless Roaming
• One card per system
SPN-SC01 DCH-Q (AP)
SC-2154 SHS DCQ PROG-CA
151275 1
DCH Card
• For Wireless Roaming
• One card per Tie Line Route
• Installed with DTI card
SYSTEM CAPACITY WITHOUT EXPMEM WITH EXPMEM
SMDR Call Record 1,600 27,000
Table 4-4 Application Processor (AP) Cards (Continued)
ABBR. NAME CODE
PART
NUMBER
PORT REMARKS
