Chapter 4 Circuit Cards
Line/Trunk (LT) Cards
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 47
DAT
PN-4DATC
150015
8
4-circuit Digital Announcement Trunk
• Maximum of 120 seconds each.
TNT
PN-TNTA
151210
4
2-line Tone Trunk
AMP
PN-2AMPA
151211
4
Amplifier Trunk
VCT
SPN-4VCTI-A
IP TRK BUS CA
SC-2915 IXS VCT PROG-B2
150133
4
4-channel CODEC Card
• For IP Trunk VoIP
(CCIS/ Point-to-Multipoint)
• For connection with NEAX 2000
IVS
2
/NEAX 2400 IMX without
Peer-to-Peer connection
SPN-4VCTI-B
IP TRK BUS CA
SC-2969 IXS VCT PROG-C1
150136
4
4-channel CODEC Card
• For IP Trunk VoIP
(H.323)
CSI
SPN-2CSIA
SP-3174 BSI PROG-A
150213
8
ZT Interface
• For S-Interface
• Maximum eight per PIM
• PZ-PW122 is required.
SPN-2CSIH
SP-3174 BSI PROG-A
151224
8
ZT Interface
• For U-Interface
• Maximum eight per PIM
• PZ-PW122 is required.
Optical
Modem
PN-M10
150228
0
Optical Interface Card
• For DTI/CCIS/Remote PIM
connections.
• One PN-M10 accommodates two
DTI/CCT/DAI links.
DK00
PN-DK00
151203
0
External Relay Contact Control/Scanning
(eight circuits per card)
• Works in either mode:
Control Scanning
8-circuit 0-circuit
4-circuit 4-circuit
0-circuit 8-circuit
Table 4-3 Line/Trunk (LT) Cards (Continued)
