Attendant console, Figure 6-7, Attendant console cable connection – NEC NEAX 2000 IPS User Manual
Page 72: Desk console (sn716 deskcon)
NEAX 2000 IPS Configuration Guide
Page 62
NDA-24347, Issue 1
External Cabling
Chapter 6 Cabling
Attendant Console
Desk Console (SN716 DESKCON)
Figure 6-7 Attendant Console Cable Connection
or
LTC 3
LTC 0
P
W
0
0
D
L
C
Installation Cable
SN716
DESKCON
MDF
PIM
Slot 00 to 11
with 8DLCP: Maximum 984 ft. (300 m)
with 4DLCM/4DLCQ/2DLCN: Maximum 3937 ft. (1200 m)
or
LTC 3
LTC 0
D
L
C
Installation Cable
SN716
DESKCON
MDF
PIM
Slot 00 to 11
with 8DLCP: Maximum 984 ft. (300 m)
with 4DLCM/4DLCQ/2DLCN: Maximum 3937 ft. (1200 m)
When using PN-PW00
When using AC Adapter
