Chapter 2 System Configuration Floor-standing Installation
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 9
Floor-standing Installation
In Floor-standing Installation, the NEAX 2000 IPS is comprised of up to eight Port
Interface Modules (PIMs).
Figure 2-2 Floor-standing Installation
BASE
PIM 0
PIM 0
PIM 1
PIM 0
PIM 1
PIM 2 PIM 2
PIM 3
PIM 1
PIM 0
BASE BASE BASE
(64 ports) (128 ports) (192 ports) (256 ports)
PIM 2
PIM 3
PIM 1
PIM 0
BASE
(320 ports)
BASE
PIM 4
PIM 2
PIM 3
PIM 1
PIM 0
BASE
(384 ports)
PIM 4
PIM 5
BASE
PIM 2
PIM 3
PIM 1
PIM 0
BASE
PIM 4
PIM 5
PIM 6
BASE
(448 ports)
PIM 2
PIM 3
PIM 1
PIM 0
BASE
PIM 6
PIM 7
PIM 5
PIM 4
BASE
(512 ports)
