NEAX 2000 IPS Configuration Guide
Page 76 NDA-24347, Issue 1
Dterm IP Login/Logout Chapter 7 Dterm IP
Dterm IP Login/Logout
To connect the Dterm IP to the network, registration of the ID for each Dterm IP is
required. To provide the security, the password for Dterm IP can be registered to the
system, which administers and identifies the password.
Follow the registration procedure as shown below.
Dterm IP Login Note:
The ID registration is determined by CM08>513. Before registering the ID,
program the system data.
• ID registration without password (Authentication by MAC Address)
When you start up the Dterm IP, the following appears on the LCD.
Figure 7-1 Dterm IP Display (ID Registration without Password)
STEP 1: Enter the station number of the Dterm IP to the first row behind Login.
After the first registration, Login operation is not required.
• ID registration with password (Login Mode)
When you start up the Dterm IP, the following appears on the LCD.
Figure 7-2 Dterm IP Display (ID Registration with Password)
STEP 2: Register the password to the system by CM2B.
STEP 3: Enter the station number of the Dterm IP to the first row behind Login.
STEP 4: Press Set key (Softkey).
L o g i n :
C a n c e l B K O K
L o g i n :
C a n c e l B K O K
P a s s w d :
S e t
