Page 77: External alarm display panel
Chapter 6 Cabling
External Cabling
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 67
External Alarm
Display
The NEAX 2000 IPS can provide an optional external alarm display unit (ALM
DSPP) to indicate Power-ON/OFF, Major Alarm, and Minor Alarm status.
Figure 6-13 External Alarm Display Connection
Table 6-12 External Alarm Display Panel
NAME CODE
PART
NUMBER
QTY
REMARKS
ALM DSPP
151300
1
per System
External Alarm Display Panel
Slot 13
MDF
Power Cable (locally provided)
–27 V
LTC0
Installation Cable
ALM DSPP
G
MJ
MN
M
P
P
W
R
PWR MJ MN
PIM
LTC O
Power
Cable
(locally
provided)
