Chapter 2 System Configuration
19-inch Rack-mounting Installation
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 11
19-inch Rack-mounting Installation
The NEAX 2000 IPS can be mounted in the IEC-standard 19-inch rack. A maximum
of four PIMs can be mounted in this way.
Figure 2-4 19-inch Rack-mounting Installation
19-inch Bracket (B)
19-inch Bracket (A)
