Chapter 7 Dterm IP Dterm IP Setup
NEAX 2000 IPS Configuration Guide
NDA-24347, Issue 1
Page 73
Note 1:
For the IP Address of the DNS server, ask the network administrator.
Note 2:
Only VLAN tag is available.
Note 3:
Do not set the VLAN ID Number 0 and 1.
STEP 8: After you finish setting User Menu items, you can start setting Administrator
Menu items. To display Administrator Menu, stay in the User Menu and
press Hold, #, 0 keys in that order. The Administrator Menu appears on the
LCD. At this time, you can use Up and Down softkeys to scroll the menu
indication.
STEP 9: Select the setting item by pressing digit keys, and set the required data. Then
press Set key. When you press the Set key, the LCD returns to the Menu
indication. Repeat settings for the required items.
Table 7-2 shows the setting
items on the Administrator Menu.
7 DNS
1. DNS
Address
XXX.XXX.XXX.XXX
Enter the IP Address of the
DNS server when the DNS
server is used.
Note 1
2. DNS
Domain
Name DNS Domain Name
Enter the Domain Name of
the DNS server.
3. DRS
Name
DRS Name
Enter the Domain Name of
the DRS System-based.
8 VLAN
1. VLAN
Mode
1: VLAN Disable
2: VLAN Enable
Set when the VLAN is not
used.
Set when the VLAN is
used.
Note 2
2. VLAN
ID
VLAN ID
Number 2-4094
Note 3
Enter the VLAN IP
number.
3. VLAN
Priority
VLAN Priority
Number 0-7
Enter the Priority number
of the VLAN.
• When the HUB has no
function to give priority
to a packet, no setting is
required.
9 System Information -
Select when displaying the
list of current settings.
Table 7-1 User Menu Items (Continued)
MENU
NO.
INDICATION SETTING DATA DESCRIPTION
