SYSTEM PROGRAMMING STEPS
TUNER
1
2
SOURCE
3
4
SOURCE
POWER OR
DISCRETE "ON"
DISCRETE "OFF"
SOURCE
5
7
6
8
IR COMMANDS
POWER
PROGRAM
ENTER
IR
NEXT
RED LED GREEN LED
Step 11
- T
o program a sequence for Source 3,
press the keys on the Niles R-8 Remote that cor-
respond to the commands you wish to include in
the sequence. Otherwise, skip to
Step 12.
Enter commands and delays from the
ZR-8630AV Source Component Programming
Worksheet in the order you wish them to
occur. The sequence may include as many as
64 commands and/or delays. To include a delay,
use the Volume + key (1 second) or Volume - key
(.5 second).
The
ENTER IR LED blinks when it receives a command.
TUNER
1
2
SOURCE
3
4
SOURCE
POWER OR
DISCRETE "ON"
DISCRETE "OFF"
SOURCE
5
7
6
8
IR COMMAND
POWER
PROGRAM
ENTER
IR
NEXT
RED LED GREEN LED
PROGRAM
ENTER
IR
NEXT
Step 12 -
After entering all commands
and/or delays for the Source 3
sequence, press the
NEXT button.
TUNER
1
2
SOURCE
3
4
SOURCE
POWER OR
DISCRETE "ON"
DISCRETE "OFF"
SOURCE
5
7
6
8
IR COMMANDS
POWER
PROGRAM
ENTER
IR
SEQUENCE
NEXT
RED LED GREEN LED
The
ENTER IR
LED lights RED.
The
SOURCE 3/4
LED turns GREEN
indicating Source 4.
The
POWER OR
DISCRETE “ON”
LED blinks RED.
The
SEQUENCE
LED turns OFF
.
Step 13 - T
o program Sources 4 through 8, follow
Steps 4 through 1
1
above. Remember that the SOURCE #/# LED is
RED for odd-numbered sources and GREEN for even-numbered sources.
Step 14 - T
o exit the programming mode,
tap the
PROGRAM button.
PROGRAM
ENTER
IR
NEXT
Step 10 - Press the NEXT button.
TUNER
1
2
SOURCE
3
4
SOURCE
POWER OR
DISCRETE "ON"
DISCRETE "OFF"
SOURCE
5
7
6
8
IR COMMANDS
POWER
PROGRAM
ENTER
IR
SEQUENCE
NEXT
RED LED GREEN LED
The
ENTER IR
LED lights RED.
The
IR COMMANDS
LED turns OFF
.
The
SEQUENCE
LED blinks RED.
