PARTS GUIDE (I
NTELLIPAD ® C
I KEYPAD MODULES
)
SOLD SEPARATELY
Figure 3
*
Function Keys
Master Keys
Zone Off Key
Mute Key
Zone Volume Key
Select ™ Master
Keypad Module
Transport™ Accessory
Keypad Module
Numeric ™ Accessory
Keypad Module
Solo™ Master
Keypad Module
Master Keys
Function Keys
Mute Key
Zone Volume Key
Zone Off Keys
NOTE: Select ™ and Solo ™ Master Keypad Modules
with an integrated IR sensor are available. They
accept IR commands from the Niles R-8 Remote.
Master Keys
T ap any of these keys once to turn on the zone and
select a source component. Press and hold these keys
to turn on all enabled zones and select the same source
component in all zones.
Zone OFF Key
T
ap this key once to turn OFF your specific zone. Press
and hold to turn OFF all zones.
V olume Keys
Press and hold these to raise or lower the volume in
your specific zone, or to restore sound in a muted zone.
Zone Mute Key
T
ap this key once to mute the sound in a zone, or to
restore the sound in a muted zone.
Function Keys
Press and hold these keys to issue the individual IR
commands programmed to control the connected
source components.
