CONNECTIONS

6. High-Output Flasher to the Flasher Outputs

Connect the mini-plug end of a Niles High-Output

Flasher, Model IRC-1P (FG00932), to the Flasher Output
labeled ALL. Strategically position the IRC-1P to provide
IR transmission to all source components. It adheres with
a Velcro mounting system (included).

SOURCE-COMPONENT HOME THEA

TER

SYNCHRONIZATION SIGNALS

7. 12V Home Theater Sync to Home Theater Sync Input

Connect the 12V Home Theater sync signal to the Home

Theater sync input with a mini-plug.

12V

CONTROL SIGNALS

8. 12V Control Outputs to Voltage-Triggered Devices

T

he 12V control outputs, Main, and Zones 4, 5, and 6

connect to the trigger input of a voltage-activated device
(i.e., Niles AC-3) with the mini-plug end of a Niles
Accessory Cable (FG00724).

HOME THEA

TER CONTROL SYSTEM

9. IR Output from a Home Theater Control System to the

IR Input

Connect a Home Theater Control System to the IR Input of

the ZR-8630AV with the mini-plug end of a Niles
Accessory Cable (FG00724).

AM/FM ANTENNAS

0. AM Loop Antennas

Connect the bare-wire ends of the

AM Loop Antennas

(included) to the spring-loaded AM and GND terminals
on the ZR-8630AV. Then position and mount the
antennas for proper reception.

1. Coaxial Cables to FM Antenna Assembly

Connect the F-connectors on the two male-to-male

coaxial cables (included) to the two female coaxial F-
connectors on the ZR-8630AV, and to the signal splitter’s
two female coaxial F-connectors (labeled OUT).

1. Signal Splitter

The signal splitter divides the signal from the FM Dipole

Antenna to supply both FM tuners in the ZR-8630AV.

3. FM Dipole Antenna

Connect the male coaxial F-connector of the FM Dipole

Antenna (included) to the signal splitter’s single female
coaxial F-connector (labeled IN). Then position and
mount the antenna for proper reception.

SPEAKERS

1. Zones 1-6

Use Niles no-strip connectors to attach wires from the

ZR-8630AV to the speakers in the listening zones.

1.

Zone

Video Outputs

Six RCA

jacks provide zoned output connections for TVs

and video displays.

PREAMPLIFIER ZONE OUTPUTS

1. Zones 1-6 (4-6 set to Variable Mode)

For more power in a zone, connect Individual Zone

Preamplifier Outputs 1-6 to an external amplifier with
male-to-male RCA

audio cables. (See System

Configurations 8 and 9 for more details.)

1. Zones 4-6 Set to Fixed Mode

For more rooms/power in a zone, connect Individual

Zone Preamplifier Outputs 4-6 (set to fixed output mode)
to an external amplifier with male-to-male RCA audio
cables. (See Configuration 10 for more details.)

KEYP

AD MODULES

1. Keypads to Keypad Inputs for Zones 1-6

Connect the keypads to the zoned keypad inputs with

four-pair twisted cable terminated with male RJ-45 plugs.
(See page 47, Terminating Four-Pair Twisted Cable, for
more information.)

SYSTEM EXP

ANSION

1. System Expansion Input to System Expansion Output

Connect multiple ZR-8630A

V units with four-pair

twisted cable, terminated with male RJ-45 plugs, using
the system-expansion input and output terminals. Make
connections from the input of one ZR-8630AV to the
output of another, and so on. (See page 47, Terminating
Four-Pair Twisted Cable, for more information.)

AC POWER

1. Removable AC Power Cord

Connect the removable

AC power cord (included with

the ZR-8630AV) to the power-cord socket and to an AC
power outlet.
