Event 1

Pressing a Master Key or a Sour

ce Button turns a ZONE ON.

Pressing and holding a Master Key/Source Button turns all
zones on to that source. (The zone must be enabled with a
DIP switch. See Installation Settings for more details.) When
a zone is on, the selected Master Key illuminates green.

Event 2

Pressing or pressing and holding a Master Key/Sour

ce Button

selects the proper input programmed for that Master
Key/Source Button. The internal tuner 1 is the source for
Master Key 1 on the Master Keypad Modules and the Tuner
1 Source Button on the R-8 Remote. The internal tuner 2 is
the source for Master Key 2 on the Master Keypad Modules
and the Tuner 2 Source Button on the R-8 Remote. Master
Keys/Source Buttons 3 through 8 are for the corresponding
external audio inputs.

Event 3

Pressing a Master Key/Sour

ce Button turns ON IR-

activated source components (i.e., DSS, VCR). The Source
ON event occurs only for Master Keys/Source Buttons 3
through 8.

Power commands for each Master

Key/Source

Button are programmed individually and occur condition-
ally, synchronized by the corresponding sync inputs.

Event 4

This event is executed last. The sequence typically includes

play, group, file, or channel commands for an associated
source component. You can program the sequence for
Master Keys/Source Buttons 3 through 8 with the IR com-
mands taught to their respective function keys, and with pro-
grammed time delays. You can program the sequences for
the Tuner Source Keys with the tuners’ direct access or pre-
set access commands. (Source-in-Use Indication affects this
event. See page 45.)

Master Key/Source Button Events
When you press a Master Key on a Master Keypad Module or a Sour

ce Button on the hand-held R-8 Remote, as

many as four events occur.

The first two events are factory-programmed: Event 1 activates the zone in which you are located. Event 2 selects
the proper source input corresponding to the Master Key or Source Button you press (1 = Tuner 1, 2 = Tuner 2,
3 = Input 3, 4 = Input 4, etc.).

Two installer-programmable events are available for Master Keys and Source Buttons 3 through 8: Event 3 is the
Source ON Event, and Event 4 is the Sequence Event.

Because no power command is required for the internal tuners of the ZR-8630AV, Master Keys 1 and 2 and the
Tuner Source Buttons are programmable only with the Sequence Event.

OPERATIONAL OVERVIEW

Master Key/

Source Button

Event 1

(Zone ON)

Event 2

(Input)

Event 3

(Source ON)

Event 4

(Sequence)

Master Key 1 or

Tuner 1 Source Button

urns Zone On

(Factory Programmed)

Selects Tuner 1

(Factory Programmed)

Not Available

Installer Programmed

Master Key 2 or

Tuner 2 Source Button

urns Zone On

(Factory Programmed)

Selects Tuner 2

(Factory Programmed)

Not Available

Installer Programmed

Master Key 3 or

Source Button 3

urns Zone On

(Factory Programmed)

Selects Input 3

(Factory Programmed)

Installer Programmed

Master Key 4 or

Source Button 4

urns Zone On

(Factory Programmed)

Selects Input 4

(Factory Programmed)

Installer Programmed

Master Key 5 or

Source Button 5

urns Zone On

(Factory Programmed)

Selects Input 5

(Factory

Programmed

Installer Programmed

Master Key 6 or

Source Button 6

urns Zone On

(Factory Programmed)

Selects Input 6

(Factory Programmed)

Installer Programmed

Master Key 7 or

Source Button 7

urns Zone On

(Factory Programmed)

Selects Input 7

(Factory Programmed)

Installer Programmed

Master Key 8 or

Source Button 8

urns Zone On

(Factory Programmed)

Selects Input 8

(Factory Programmed)

Installer Programmed
