64

PROGRAM

ENTER

IR

NEXT

Step 4 - If the component connected as Sour

ce 3 has IR commands for turning on and off, skip to

Step 5.

If the component connected as Sour

ce 3 turns on with a switched outlet or remains on continually, press the

NEXT

button twice and skip to Step 7.

SYSTEM PROGRAMMING STEPS

Step 3 -

T

o program a sequence for Tuner 2, press the keys on the Niles R-8 Remote that correspond to the commands you

wish to include in the sequence. Otherwise, press the

NEXT button and skip to Step 4.

Enter commands and delays from the ZR-8630AV Programming Worksheet in the order you wish them to occur. The
sequence may include as many as 64 commands and/or delays. To include a delay, use the Volume + key (1 second) or
Volume - key (.5 second).

The

POWER OR DISCRETE

“ON”

LED blinks RED.

The

ENTER IR LED

lights RED.

The

SOURCE 3/4 LED lights

RED indicating Source 3.

TUNER

1

2

SOURCE

3

4

SOURCE

POWER OR
DISCRETE "ON"

DISCRETE "OFF"

SOURCE

5

7

6

8

IR COMMANDS

POWER

PROGRAM

ENTER

IR

SEQUEN

NEXT

RED LED GREEN LED

Press the

NEXT button

twice to skip to

Step 7.

The

PROGRAM

LED lights RED

.

The ENTER IR LED blinks

when it receives a command.

TUNER

1

2

SOURCE

3

4

SOURCE

POWER OR
DISCRETE "ON"

DISCRETE "OFF"

SOURCE

5

7

6

8

IR COMMANDS

POWER

PROGRAM

ENTER

IR

SEQUENCE

NEXT

RED LED GREEN LED

After entering all commands and/or delays for
the Tuner 2 sequence, press the

NEXT button.

TUNER

1

2

SOURCE

3

4

SOURCE

POWER OR
DISCRETE "ON"

DISCRETE "OFF"

SOURCE

5

7

6

8

IR COMMANDS

POWER

PROGRAM

ENTER

IR

NEXT

RED LED GREEN LED

The

ENTER IR

LED turns OFF

.

The

POWER OR DISCRETE

“ON”

and DISCRETE “OFF”

LEDs turn OFF

.

The

IR COMMANDS

LED blinks RED

.
